Pima FORCE Installation Guide

Chap. 13: Tests & Diagnostics
45
Chap. 13 Tests & Diagnostics
In the main screen, press Tests & Diagnostics . This menu includes the sub-menus that follows.
1)  Event Memory
2)  Zone Test. See below.
3)  Output Test
4)  Power Diagnostics
5)  Communication Tests
6)  Comm. Monitor
13.1 Event Memory
Tests & Diagnostics  Event Memory
The Event Memory stores up to 1,000 events. Each event is made of a time stamp, the event
description, and the event source.
Scroll through the events using the up/down arrow keys.
13.2 Zone Test
Tests & Diagnostics  Zone Test
The Zone Test menu includes the following sub-menus:
1)  Single Zone: enter the desired zone number, trigger the detector and check the
Successfully Tested field.
2)  All Zones: walk through the entire premises, trigger the detectors and check the display:
5) Tested: the number of tested zone, out of the overall defined zones.
6) Last Tested (zone)
7)  Failed/Not Tested: a list of the zones that failed the test or were not tested.
3) Audible Indication: select from the following list:
 Keypad Buzzer
 Beep-External Siren
 Beep-Internal Siren
13.3 Output Test
Tests & Diagnostics  Output Test
The Output Test menu includes the following sub-menus, for testing the physical outputs. If an
output is not functioning properly, it helps defining whether it is a hardware or configuration
based problem:
1)  Onboard: select any of the control panel’s outputs and Activate/Deactivate it. The
available outputs are: External/Internal Siren, Relay, On/Off, Alarm .
2)  Zone Expanders: select an expander (press # or *) and Activate/Deactivate the
expander’s relay output/s. To easily locate the expander, press Activate Buzzer and
Activate/Deactivate the expander’s buzzer.
