SYMBOLS USED ON THE MACHINE
Tap symbol
Used to indicate water regulation changes. (CDS versions)
Detergent symbol
Used to indicate detergent regulation changes. (CDS versions)
Indicator showing battery charge level on the upper line and hour-counter on the lower line.
Indicator showing the type of hour-counter (total) on the upper line and the type of service (none) on
the lower line.
Indicator showing the type of technology of the batteries used (lead).
Battery symbol
Indicates the maximum temperature of the detergent solution.
Located near the solution tank inlet.
Symbol denoting brake
Located above the emergency and parking brake lever.
Indicates the risk of crushed hands.
Indicates the instructions for measuring the detergent in the canister (machine version DS only).
5
