DAILY MAINTENANCE
4. DISASSEMBLING AND CLEANING THE SQUEEGEE
2. release the
its seat.
4. Carefully the squeegee and its suction nozzle.
5. Carefully clean the squeegee rubbers.
Check the squeegee is always clean, for better drying results.
To clean it you must:
1. Remove the tube (1) from the squeegee.
Remove the squeegee, pushing the plate (2) to the left in order to
squeegee small column from its seat.
3. Pull the squeegee to the right until the left-hand small column is released from
clean the inside of
6. Reassemble all the elements.
5. DISASSEMBLING THE BRUSH
Turn the key anticlockwise to “O1. FF”.
3.
as shown in the figure. The figure shows the rotation direction to release the right-
hand brush; for the left-hand one, rotate in the opposite direction.
s are less than 15mm long.
2. Raise the base, using the lever.
With the base up, rotate the brush until it comes out of the brush-holder plate seat,
4. Always check the bristles for signs of wear. You are advised to replace the brushes
when the bristle
ATTENTION: This operation must be carried out using gloves to
protect against contact with dangerous solutions.
1
6. DISA
To remove the brushes:
1.
2.
SSEMBLING THE BRUSH (BASE WITH CYLINDRICAL BRUSHES)
Turn the key anticlockwise to “OFF”. (1)
Stop the machine moving by applying the brake lever. (2)
3. Insert the blocking pin (3) in the holes of the brake handle to prevent the lever slipping.
ATTENTION: Do not leave the machine on sloping or wet floors,
and check the parking brake is correctly applied.
2
1
3
22
