CR-06 GRUPPO SERBATOI PE340AS
06-07
10027810 AA
POS. CODICE
QTÀ
DENOMINAZIONE DESCRIPTION DESCRIPTION BENENNUNG DESCRIPCION
1 432091 1
TUBO DIAM. 38X1050 SPIRALATO CON GOMITO
PIPE TUBE
ROHR TUBO
3 220705 1
PREM. SERBATOIO SOLUZIONE PE340AS SOLUTION TANK ASSEMBLY RESERVOIR EAU PROPRE LAUGENTANK TANQUE SOLUCION
3.1 400728 1 TAPPO FILETT. D.130 FIL. D.127 PER E9719 THREADED COVER COUVERCLE FILETE GEWINDER DECKEL
TAPA FILETE
3.2 405416 1
FILTRO A TAZZA De118 Di108 H40
FILTER FILTRE FILTER
FILTRO
3.3 415750 2
VITE M5X12 TSPTC UNI 7688 (4.8) ZINC. SCREW VIS SCHRAUBE TORNILLO
3.4 410327 2 BASETTA ADES. FISSA FASCETTE ABM 25-A-C SUPPORT PLATE PLAQUE SUPPORT
STÜTZPLATTE
PLACA SOPORTE
3.5 428562 2
RACCORDO A GOMITO D=8 L=30 TIPO WS8 ELBOW COUDE WINKELVERSCHRAUBUNG RACOR CODO
3.6 217670 1
TUBO VITREO D=12 d=8 L=310 HOSE
TUYAU
SCHLAUCH TUBO DE GOMA
3.7 433497 1 SERBATOIO SOLUZIONE PE340AS SOLUTION TANK RESERVOIR EAU PROPRE FRISCHWASSERTANK TANQUE SOLUCION
3.8 428561 2
GUARNIZIONE D=20 d=8 L=12,5 TIPO PWS8 GASKET JOINT DICHTUNG
JUNTA
3.9 410349 1
PORTAGOMMA A GOMITO 3/8"x12-13 CONNECTOR RACCORD SCHLAUCHANSCHLUSS EMPALME TUBO DE GOMA
3.10 405943 1
GUARNIZIONE TAPPO D=143 GASKET JOINT DICHTUNG
JUNTA
3.11 219362 1 KIT TUBO SCARICO SERB. SOL. SIMPLA 2009 DRAIN HOSE KIT TUYAU DE VIDAGE ABLAUFROHR TUBO DE DRENAJE
4 220706 1
PREM. SERBATOIO RECUPERO PE340AS RECOVERY TANK ASSEMBLY RESERVOIR EAU SALE SCHMUTZWASSERTANK TANQUE AGUA SUCIA
4.1 433498 1
SERBATOIO RECUPERO PE340AS RECOVERY TANK RESERVOIR EAU SALE SCHMUTZWASSERTANK TANQUE AGUA SUCIA
4.2 426392 1 RACCORDO PORTAGOMMA FITTING RACCORD VERSCHRAUBUNG RACOR
4.3 426349 1
RACCORDO PORTAFILTRO G1"-1/4" RAL 7016 ELBOW COUDE WINKELVERSCHRAUBUNG RACOR CODO
4.4 405959 2
GUARNIZ. PIANA 40,4x47x2,5 PER FILTRO GASKET JOINT DICHTUNG
JUNTA
4.5 426348 1 FILTRO ASPIRAZIONE MX RAL 7016 FILTER FILTRE FILTER FILTRO
4.6 415750 3
VITE M5X12 TSPTC UNI 7688 (4.8) ZINC. SCREW VIS SCHRAUBE TORNILLO
4.7 410327 3
BASETTA ADES. FISSA FASCETTE ABM 25-A-C SUPPORT PLATE PLAQUE SUPPORT
STÜTZPLATTE
PLACA SOPORTE
4.8 410397 1 RACCORDO PORTAGOMMA DIRITTO FITTING RACCORD VERSCHRAUBUNG RACOR
5
407666
4
VITE M6X20 TE UNI 5739 ZINC SCREW VIS SCHRAUBE TORNILLO
6 408633 4
VITE M4x12 TE UNI 5739 ZINC SCREW VIS SCHRAUBE TORNILLO
7
408674 1
VITE M8x25 TE UNI 5739 ZINC SCREW VIS SCHRAUBE TORNILLO
8 408796 2 VITE M6x20 TCEI UNI 5931 ZINC SCREW VIS SCHRAUBE TORNILLO
9 409054 1
DADO M8x5 UNI 5589 ZINC
NUT
ECROU
MUTTER
TUERCA
10 409144 4
ROSETTA 4,3x12x1,5 UNI 6593 ZINC WASHER RONDELLE UNTERLAGSCHEIBE
ARANDELA
11 409160 6 ROSETTA 6x18x1,5 UNI 6593 ZINC WASHER RONDELLE UNTERLAGSCHEIBE
ARANDELA
12 409164 6
ROSETTA GROWER 6x2,5x1,8 ASA B27 ZINC LOCK WASHER RONDELLE FREIN ZAHNSCHEIBE
ARANDELLA DENTADA
13 409188 2
ROSETTA 9x18x1,5 ZINC WASHER RONDELLE UNTERLAGSCHEIBE
ARANDELA
14 410290 1 FASCETTA A VITE 32-44x12,2 CLAMP COLLIER BRIDE ABRAZADERA
16 413871 1
SOTTOFONDO BATTERIE ABS BATTERY BASE BAC LOGEMENT BATTERIES BATTERIEKASTEN PLACA ASIENTO BATERIAS
17 415824 8
VITE M6x25 TPSEI UNI5933 SCREW VIS SCHRAUBE TORNILLO
18 415941 4
ROSETTA 4 UNI1751 ZINC GROWER LOCK WASHER RONDELLE FREIN ZAHNSCHEIBE
ARANDELLA DENTADA
19 416320 2 CERNIERA GAMM MODELLO C65/A HINGE CHARNIERE SCHARNIER BISAGRA
21 420512 1
FASCETTA A VITE 27/51x12,6 INOX SCREW CLAMP COLLIER VIS BRIDE SCHRAUBE ABRAZADERA A TORNILLO
Pag. 21 di 52
