Pioneer PD-M430 - Important Safety Instructions; Electrical Safety and Precautions; Installation and Environmental Safety; Power Cord and Disc Handling Safety

IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
olen ‘lehme) ty)
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead, within an equilateral
triangie, is intended to alert the user of the presence of
uninsulated ‘dangerous voltage’’ within the product's
enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important my
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
The wire which is coloured biue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is cotoured brown must be connected
to the terminal which is marked with the letter L or
coloured red.
Neither wire is to be connected to the earth terminal
of a three pin plug.
Equipment sold in the U.K. is not supplied with a power
plug.
IMPORTANT
lf the apparatus is fitted with AC mains power outiet(s),
see REAR PANEL FACILITIES for convenient
connection of additional Hi-Fi components). Make all
connections to the AC outlet(s) and the signal terminals
first. Connect the plug to the wall socket last, make
sure that the power switch is off.
FOR USE IN THE UNITED
KINGDOM
The wires in this mains lead are coloured in
accordance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains jead of this
apparatus may not correspond with the coloured
marking identifying the terminals in your plug proceed
as follows:
SAFETY INSTRUCTIONS
OUTDOOR-ANTENNA GROUNDING — If an outside an-
tenna is connected to the antenna terminal, be sure
the antenna system is grounded so as to provide
some protection against voltage surges and built
up static charges.
in the U.S.A. section 810 of the National Electrical
Code, ANSI/NFPA No. 70-1984, provides informa-
tion with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in
POWER LINES — An outdoor antenna should be located
away from power lines.
NONUSE PERIODS — The power cord of the appliance
should be unplugged from the outlet when left un-
used for a long period of time.
OBJECT AND LIQUID ENTRY — Care should be taken
so that objects do not fall and liquids are not spilled
into the enclosure through openings.
DAMAGE REQUIRING SERVICE — The appliance
READ INSTRUCTIONS — All the safety and operating
instructions should be read before the appliance is
operated.
RETAIN INSTRUCTIONS — The operating instrucions
should be retained for future reference
HEED WARNING — All warnings on the appliance andin
the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use in-
structions should be followed.
WATER AND MOISTURE -— The appliance should not
be used near water ~ for example, near a bathtub,
washbowIl, kitchen sink, laundry tub, in a wet base-
ment, or near a swimming pool, etc.
LOCATION ~— The appliance should be installed in a
stable location.
WALL OR CEILING MOUNTING — The appliance
should not be mounted to a wall or ceiling.
should be serviced by 2 Pioneer authorized service
center or qualified service personnel when:
The power-supply cord or the plug has been dam-
aged; or
Objects have fallen, or liquid has been spilled into
the appliance; or
The appliance has been exposed to rain; or
The appliance does not appear to operate normally
wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and require-
ments for the grounding electrode. See Fig. A.
CART — An appliance and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart
combination to overturn.
2
VENTILATION — The appliance should be situated so
that its location or position does not interfere with
its proper ventilation. For example, the appliance
should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings; or,
placed in a built-in installation, such as a bookcase
Or cabinet that may impede the flow of air through
the ventilation openings.
HEAT — The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances {including amplifiers)
that produce heat.
POWER SOURCES — The appliance should be con-
nected to a power supply only of the type de-
scribed in the operating instructions or as marked
on the appliance.
POWER-CORD PROTECTION — Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords
at plugs, convenience receptacles, and the point
where they exit from the appliance.
POLARIZATION — If your purchased product is pro-
vided with a polarized power plug, please read the
following instructions, This product is equipped
with a polarized alternating current line plug {a plug
having one blade wider than the other). This plug
will fitinto the power outlet only one way. This is a
safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
CLEANING — The appliance should be cleaned oniy
with a polishing cloth or a soft dry cloth. Never
clean with furniture wax, benzine, insecticides or
other volatile liquids since they may corrode the
cabinet.
<PRB1124>
En
or exhibits a marked change in performance; or
The appliance has been dropped; on the enclosure
damaged.
SERVICING — The user should not attempt to service
the appliance beyond that described in the opera-
ting instructions. For all other servicing, contact the @
nearest Pioneer authorized service center.
NEC — NATIONAL ELECTRIC CODE
——— ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810 — 20)
ELECTRIC
SERVICE
EQUIPMENT-~-
GROUNDING CONDUCTORS
(NEC SECTION 810 ~ 21)
ame
GROUND
CLAMPS
=«——-~- POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
FIG.A
