34
En
English
Additional Information
Specifications
General (PDP-503MXE)
Light emission panel ............ 50 inch plasma display panel
Number of pixels .............................................. 1280 x 768
Power supply ............................. AC 100 - 240 V, 50/60 Hz
Rated current ................................................. 3.8 A - 1.6 A
Standby power consumption ...................................... 1 W
External dimensions ........ 1218 (W) x 714 (H) x 98 (D) mm
(including display stand)
...................................... 1218 (W) x 737 (H) x 300 (D) mm
Weight.................................................................... 38.9 kg
(including display stand) ......................................... 39.5 kg
Operating temperature range............................. 0 to 40 °C
Operating atmospheric pressure range
................................................................. 800 to 1100 hPa
General (PDP-433MXE)
Light emission panel ............ 43 inch plasma display panel
Number of pixels .............................................. 1024 x 768
Power supply ............................. AC 100 - 240 V, 50/60 Hz
Rated current ............................................. 2.98 A - 1.24 A
Standby power consumption ...................................... 1 W
External dimensions ........ 1070 (W) x 630 (H) x 98 (D) mm
(including display stand)
...................................... 1070 (W) x 653 (H) x 300 (D) mm
Weight.................................................................... 31.5 kg
(including display stand) ......................................... 32.1 kg
Operating temperature range............................. 0 to 40 °C
Operating atmospheric pressure range
................................................................. 800 to 1100 hPa
Input/output
Video
INPUT 1
Input Mini D-sub 15 pin (socket connector)
RGB signal (SYNC ON G compatible)
RGB ... 0.7 Vp-p/75 Ω/no sync.
HD/CS, VD ... TTL level
/positive and negative polarity
/2.2 kΩ
SYNC ON G
... 1 Vp-p/75 Ω/negative sync.
*Compatible with Microsoft’s Plug & Play
(VESA DDC1/2B)
Output Mini D-sub 15 pin (socket connector)
75 Ω/with buffer
Additional Information
INPUT 2
Input BNC jack (x5)
RGB signal (SYNC ON G compatible)
RGB ... 0.7 Vp-p/75 Ω/no sync.
HD/CS, VD ... TTL level
/positive and negative polarity/
75 Ω or 2.2 kΩ
(impedance switch)
SYNC ON G ...
1 Vp-p/75 Ω/negative sync.
Audio
Input AUDIO INPUT (for INPUT 1/2)
Stereo mini jack
L/R ... 500mVrms/more than 10 kΩ
Output AUDIO OUTPUT
Stereo mini jack
L/R ... 500mVrms (max)/less than 5 kΩ
SPEAKER
L/R ... 8 – 16 Ω/2W +2W (at 8 Ω)
Control
RS-232C ... D-sub 9 pin (pin connector)
COMBINATION IN/OUT
... Mini DIN 6 pin (x2)
CONTROL IN/OUT ... monaural mini jack (x2)
Accessories
Remote control unit ......................................................... 1
Remote control unit holder .............................................. 1
AA (R6) batteries .............................................................. 2
Cleaning cloth ................................................................... 1
Speed clamps ................................................................... 2
Bead bands ...................................................................... 2
Operating Instructions...................................................... 1
Display stands .................................................................. 2
Washers ........................................................................... 2
Hex hole bolts (M8X40).................................................... 2
Ferrite core ....................................................................... 1
Cable tie ........................................................................... 1
÷ Due to improvements, specifications and design are subject to
change without notice.
