PDP-435PE
38
1234
1234
C
D
F
A
B
E
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω
RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..43 ADDRESS ASSY AWV2076
NSP 2..43 ADDRESS ASSY AWZ6862
NSP 1..43 SCAN ASSY AWV2079
NSP 2..43 SCAN A ASSY AWZ6873
NSP 2..43 SCAN B ASSY AWZ6874
NSP 2..X CONNECTOR A ASSY AWZ6875
NSP 2..X CONNECTOR B ASSY AWZ6876
NSP 1..HD PANEL IF ASSY AWV2073
2..PANEL IF ASSY AWZ6841
1..DIGITAL VIDEO ASSY AWV2074
NSP 1..HD AUDIO ASSY AWV2075
2..HD AUDIO AMP ASSY AWZ6863
2..HD SP TERMINAL ASSY AWZ6864
NSP 1..43 X DRIVE ASSY AWV2077
2..PANEL LED ASSY AWZ6842
2..PANEL KEY ASSY AWZ6843
2..KEY CONTROL ASSY AWZ6844
2..PANEL IR ASSY AWZ6845
2..43 X DRIVE ASSY AWZ6865
2..PANEL SENSOR ASSY AWZ6872
1..43 Y DRIVE ASSY AWV2078
>
1..POWER SUPPLY UNIT AXY1085
Mark No. Description Part No.
43 ADDRESS ASSY
[43 ADR LOGIC BLOCK]
SEMICONDUCTORS
IC1501 PEE001B
COILS AND FILTERS
L1504 QTL1013
CAPACITORS
C1501, C1502 ACH1357
C1509, C1510 CKSSYB102K50
C1503-C1507, C1555, C1558, C1561 CKSSYF104Z16
C1564 CKSSYF104Z16
RESISTORS
R1510, R1519, R1522 RAB4C470J
R1505-R1509, R1530, R1531 RS1/16SS1000F
R1511-R1518, R1520, R1521, R1523 RS1/16SS470J
R1524, R1536-R1539 RS1/16SS470J
Other Resistors RS1/16S###J
OTHERS
CN1501 40P FFC CONNECTOR AKM1215
[43 ADR RESONANCE BLOCK]
SEMICONDUCTORS
IC1601-IC1603 TND307TD
Q1604 2SA1163
Q1601 HAT1110R
Q1602, Q1603 HAT3021R
D1601 1SS302
D1605-D1608 RF051UA1D
D1602-D1604 UDZS15(B)
COILS AND FILTERS
L1601, L1602 ATH1163
CAPACITORS
C1605 (0.1U/100V) ACG1098
C1607, C1615 (0.1UF/100V) ACG1121
C1613 ACH1357
C1603 (47UF/16V) ACH1391
C1601, C1602 (56UF/80V) ACH1405
C1609, C1614 CKSRYB104K25
C1604, C1608, C1612 CKSSYF104Z16
RESISTORS
R1620 ACN1174
R1602,R1608-R1611 RS1/16SS220J
To Next Page
