Pioneer PDP-435PG - DATA LOGS AND STATUS; DESCRIPTION ON POWER-DOWN; GPW: PANEL WHITE-BALANCE ADJUSTMENT VALUES; GS1: INFORMATION ON THE UNIT, SOFTWARE VERSION

PDP-435PE
52
1234
1234
C
D
F
A
B
E
000
000
000
000
000
000
000
000
000
000
255
255
255
255
255
255
255
255
255
255
[X]
XD1
XD2
XU1
XU2
[Y]
YD1
YD2
YD3
YD4
YU1
YU2
XSUS-D-1
XSUS-D-2
XSUS-U-1
XSUS-U-2
YSUS-D1-1
YSUS-D1-2
YSUS-D2-1
YSUS-D2-2
YSUS-U-1
YSUS-U-2
XSUS-D-1 adjustment
XSUS-D-2 adjustment
XSUS-U-1 adjustment
XSUS-U-2 adjustment
YSUS-D1-1 adjustment
YSUS-D1-2 adjustment
YSUS-D2-1 adjustment
YSUS-D2-2 adjustment
YSUS-U-1 adjustment
YSUS-U-2 adjustment
Command Name Function
Validity of direct numeric input
Validity Lower limit Upper limit
?
?
?
?
?
?
?
?
?
?
Command description
Command Function
GAJ Obtaining various adjustment values
GNP
GPD Obtaining power-down-point log
Obtaining serial number of the panel side
GPW Obtaining panel white-balance adjustment values
GS1 Obtaining information on the unit, such as the software version
GS2 Obtaining information on the status of the unit
GSD Obtaining information on shutdown
GAJ: Obtaining data on ABL setting values, electronic-control adjustment values, and drive-system adjustment values
Note: Ignore the 2-byte checksum at the end.
Order Data Size Remarks
1 ABL table currently used 3 bytes AB1 - AB3
2 ABL adjustment value 3 bytes 000 - 255
3 Vsus adjustment value 3 bytes 000 - 255
4 Vofs adjustment value 3 bytes 000 - 255
5 X-SUS-U1 adjustment value (XU1) 3 bytes 000 - 255
6 X-SUS-U2 adjustment value (XU2) 3 bytes 000 - 255
7 X-SUS-D2 adjustment value (XD2) 3 bytes 000 - 255
8 X-SUS-D1 adjustment value (XD1) 3 bytes 000 - 255
9 Y-SUS-U1 adjustment value (YU1) 3 bytes 000 - 255
10 Y-SUS-U2 adjustment value (YU2) 3 bytes 000 - 255
11 Y-SUS-D1-2 adjustment value (YD2) 3 bytes 000 - 255
12 Y-SUS-D1-1 adjustment value (YD1) 3 bytes 000 - 255
13 Y-SUS-D2-2 adjustment value (YD4) 3 bytes 000 - 255
14 Y-SUS-D2-1 adjustment value (YD3) 3 bytes 000 - 255
