GPD: Obtaining power-down-point log on the panel
GNP: Obtaining serial number of the panel side
Note: Ignore the 2-byte checksum at the end.
Order Data Size Remarks
1
Panel serial number
15 bytes
Alphanumeric, space, underbar, slash
Order Data Size Remarks
1
Latest "1st PD" data
1 byte
0-D or F
2
Latest "2nd PD" data
1 byte
0-D or F
3
Data of hour meter for the latest PD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
4
Data on temperature for the latest PD (TEMP1)
3 bytes 000 - 255
5
Second latest "1st PD" data
1 byte
0-D or F
6
Second latest "2nd PD" data
1 byte
0-D or F
7 Data of hour meter for the second latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
8 Data on temperature for the second latest PD (TEMP1) 3 bytes 000 - 255
9 Third latest "1st PD" data 1 byte
0-D or F
10 Third latest "2nd PD" data 1 byte
0-D or F
11 Data of hour meter for the third latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
12 Data on temperature for the third latest PD (TEMP1) 3 bytes 000 - 255
13 Fourth latest "1st PD" data 1 byte
0-D or F
14 Fourth latest "2nd PD" data 1 byte
0-D or F
15 Data of hour meter for the fourth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
16 Data on temperature for the fourth latest PD (TEMP1) 3 bytes 000 - 255
17 Fifth latest "1st PD" data 1 byte
0-D or F
18 Fifth latest "2nd PD" data 1 byte
0-D or F
19 Data of hour meter for the fifth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
20 Data on temperature for the fifth latest PD (TEMP1) 3 bytes 000 - 255
21 Sixth latest "1st PD" data 1 byte
0-D or F
22 Sixth latest "2nd PD" data 1 byte
0-D or F
23 Data of hour meter for the sixth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
24 Data on temperature for the sixth latest PD (TEMP1) 3 bytes 000 - 255
25 Seventh latest "1st PD" data 1 byte
0-D or F
26 Seventh latest "2nd PD" data 1 byte
0-D or F
27 Data of hour meter for the seventh latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
28 Data on temperature for the seventh latest PD (TEMP1) 3 bytes 000 - 255
29 Eighth latest "1st PD" data 1 byte
0-D or F
30 Eighth latest "2nd PD" data 1 byte
0-D or F
31 Data of hour meter for the eighth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
32 Data on temperature for the eighth latest PD (TEMP1) 3 bytes 000 - 255
Notes: • Ignore the 2-byte checksum at the end.
• For details, see "Description on power-down."
