PDP-435PE

5678

PDG054A (DIGITAL VIDEO ASSY : IC5401)

Ball No. No. Pin Name Function

A1 1 BAI_6 A phase signal input of B video (sixth bit)

B1 2 BAI_5 A phase signal input of B video (fifth bit)

C1 3 BAI_4 A phase signal input of B video (fourth bit)

D1 4 NC NC pin

E1 5 NC NC pin

F1 6 BAI_3 A phase signal input of B video (fifth bit)

G1 7 BAI_2 A phase signal input of B video (fourth bit)

H1 8 FIELD FIELD signal input

J1 9 XSUSB_12 X-Drive control signal output

K1 10 XSUSB_10 X-Drive control signal output

L1 11 XSUSB_4 X-Drive control signal output

M1 12 XSUSB_0 X-Drive control signal output

N1 13 XSUSA_10 X-Drive control signal output

P1 14 XSUSA_4 X-Drive control signal output

R1 15 XSUSA_2 X-Drive control signal output

T1 16 ADRS_0 Address control signal output

U1 17 AD6TXOUT3M Address LVDS signal output

V1 18 AD6TXCLKOUTM Address LVDS signal output

W1 19 AD6TXOUT2M Address LVDS signal output

Y1 20 AD6TXOUT1M Address LVDS signal output

AA1 21 AD6TXOUT0M Address LVDS signal output

AB1 22 AD7TXOUT3M Address LVDS signal output

AC1 23 AD7TXCLKOUTM Address LVDS signal output

AD1 24 AD7TXOUT2M Address LVDS signal output

AE1 25 AD7TXOUT1M Address LVDS signal output

AF1 26 AD7TXOUT0M Address LVDS signal output

AF2 27 AD7TXOUT0P Address LVDS signal output

AF3 28 VSSLA GND

AF4 29 AD3TXOUT3M Address LVDS signal output

AF5 30 AD3TXCLKOUTM Address LVDS signal output

AF6 31 AD3TXOUT2M Address LVDS signal output

AF7 32 AD3TXOUT1M Address LVDS signal output

AF8 33 AD3TXOUT0M Address LVDS signal output

AF9 34 AD2TXOUT3M Address LVDS signal output

AF10 35 AD2TXCLKOUTM Address LVDS signal output

AF11 36 AD2TXOUT2M Address LVDS signal output

AF12 37 AD2TXOUT1M Address LVDS signal output

AF13 38 AD2TXOUT0M Address LVDS signal output

AF14 39 AD1TXOUT3M Address LVDS signal output

AF15 40 AD1TXCLKOUTM Address LVDS signal output

AF16 41 AD1TXOUT2M Address LVDS signal output

AF17 42 AD1TXOUT1M Address LVDS signal output

AF18 43 AD1TXOUT0M Address LVDS signal output

AF19 44 AD0TXOUT3M Address LVDS signal output

AF20 45 AD0TXCLKOUTM Address LVDS signal output

AF21 46 AD0TXOUT2M Address LVDS signal output

AF22 47 AD0TXOUT1M Address LVDS signal output

AF23 48 AD0TXOUT0M Address LVDS signal output

AF24 49 VSSL15 GND

AF25 50 AD4TXOUT3P Address LVDS signal output

• PDP ASIC IC4

Pin Function (1/10)
