PDP-435PE

5678

Ball No. No. Pin Name Function

B2 101 BAI_8 A phase signal input of B video (eighth bit)

C2 102 BAI_7 A phase signal input of B video (seventh bit)

D2 103 GND GND

E2 104 NC NC

F2 105 NC NC

G2 106 BAI_1 A phase signal input of B video (first bit)

H2 107 XSUSB_15 X-Drive control signal output

J2 108 GND GND

K2 109 XSUSB_9 X-Drive control signal output

L2 110 XSUSB_3 X-Drive control signal output

M2 111 XSUSA_15 X-Drive control signal output

N2 112 XSUSA_9 X-Drive control signal output

P2 113 GND GND

R2 114 XSUSA_1 X-Drive control signal output

T2 115 TEST2 Test signal input (Not used)

U2 116 AD6TXOUT3P Address LVDS signal output

V2 117 AD6TXCLKOUTP Address LVDS signal output

W2 118 AD6TXOUT2P Address LVDS signal output

Y2 119 AD6TXOUT1P Address LVDS signal output

AA2 120 AD6TXOUT0P Address LVDS signal output

AB2 121 AD7TXOUT3P Address LVDS signal output

AC2 122 AD7TXCLKOUTP Address LVDS signal output

AD2 123 AD7TXOUT2P Address LVDS signal output

AE2 124 AD7TXOUT1P Address LVDS signal output

AE3 125 VSSLA GND

AE4 126 AD3TXOUT3P Address LVDS signal output

AE5 127 AD3TXCLKOUTP Address LVDS signal output

AE6 128 AD3TXOUT2P Address LVDS signal output

AE7 129 AD3TXOUT1P Address LVDS signal output

AE8 130 AD3TXOUT0P Address LVDS signal output

AE9 131 AD2TXOUT3P Address LVDS signal output

AE10 132 AD2TXCLKOUTP Address LVDS signal output

AE11 133 AD2TXOUT2P Address LVDS signal output

AE12 134 AD2TXOUT1P Address LVDS signal output

AE13 135 AD2TXOUT0P Address LVDS signal output

AE14 136 AD1TXOUT3P Address LVDS signal output

AE15 137 AD1TXCLKOUTP Address LVDS signal output

AE16 138 AD1TXOUT2P Address LVDS signal output

AE17 139 AD1TXOUT1P Address LVDS signal output

AE18 140 AD1TXOUT0P Address LVDS signal output

AE19 141 AD0TXOUT3P Address LVDS signal output

AE20 142 AD0TXCLKOUTP Address LVDS signal output

AE21 143 AD0TXOUT2P Address LVDS signal output

AE22 144 AD0TXOUT1P Address LVDS signal output

AE23 145 AD0TXOUT0P Address LVDS signal output

AE24 146 VSSL15 GND

AE25 147 AD4TXCLKOUTP Address LVDS signal output

AD25 148 AD4TXOUT2P Address LVDS signal output

AC25 149 AD4TXOUT1P Address LVDS signal output

AB25 150 AD4TXOUT0P Address LVDS signal output

PDG054A (DIGITAL VIDEO ASSY : IC5401)

• PDP ASIC IC4

Pin Function (3/10)
