(1) PACKING PARTS LIST
(2) CONTRAST TABLE
PDP-436SXE/WYVIXK5, PDP-436RXE/WYVIXK5 and WYVI5 are constructed the same except for the following:
Mark
No. Description Part No.
1 Remote Control Unit See Contrast table (2)
2 Battery Cover AZA7424
NSP 3 Dry Cell Battery (R6P, AA) VEM1031
> 4Power Cord (2 m) ADG1214
5 Cleaning cloth AED1285
> 6Ferrite Core ATX1039
NSP 7 Warranty ARY1114
8 Operating Instructions See Contrast table (2)
(Italian, Spanish, Dutch)
9 Operating Instructions See Contrast table (2)
(English, French, German)
10 Caution Card ARM1232
11 Cleaning Caution ARM1283
12 Vinyl Bag AHG1337
13 Air Cap Bag AHG1367
14 Power Cord Case See Contrast table (2)
15 Block Diagram See Contrast table (2)
16 Polyethylene Bag See Contrast table (2)
NSP 17 Vinyl Bag AHG1340
18 Pad (T-L) See Contrast table (2)
19 Pad (T-R) See Contrast table (2)
20 Pad (B-L) See Contrast table (2)
21 Pad (B-R) See Contrast table (2)
22 Under Carton See Contrast table (2)
23 Upper Carton See Contrast table (2)
24 Mirror Mat See Contrast table (2)
25 WEEE Label AAX3271
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVIXK5
PDP-436RXE
/WYVI5
1 Remote Control Unit AXD1515 AXD1516 AXD1516
8 Operating Instructions (Italian, Spanish, Dutch) ARC1553 ARC1552 ARC1551
9 Operating Instructions (English, French, German) ARE1407 ARE1406 ARE1405
14 Power Cord Case AHC1076 AHC1076 AHC1075
15 Block Diagram ARY1183 ARY1183 Not used
16 Polyethylene Bag AHG1326 AHG1326 Not used
NSP 16 Vinyl Bag Not used Not used AHG1340
18 Pad (436XE T-L) AHA2524 AHA2524 Not used
18 Pad (436SX T-L) Not used Not used AHA2467
19 Pad (436XE T-R) AHA2525 AHA2525 Not used
19 Pad (436SX T-R) Not used Not used AHA2468
20 Pad (436XE B-L) AHA2526 AHA2526 Not used
20 Pad (436SX B-L) Not used Not used AHA2469
21 Pad (436XE B-R) AHA2527 AHA2527 Not used
21 Pad (436SX B-R) Not used Not used AHA2470
22 Under Carton (436XE) AHD3454 AHD3454 Not used
22 Under Carton (436) Not used Not used AHD3346
23 Upper Carton (436SXE) AHD3445 Not used Not used
23 Upper Carton (436RXE) Not used AHD3444 AHD3467
24 Mirror Mat AHG1327 AHG1327 AHG1284
