6.5 OUTLINE OF COMMANDS
QS1: Returning information on the module and the version of the software.
QS6: Returning information of the Flash Device.
QMT: Returning information of temperature and FAN speed.
Order Part Data Content Size Remarks
0-Received Command Name 3 byte 'QS1' only
1
DIGITAL
Display Information 1 1 byte
2 Display Information 2 1 byte
3 Display Information 3 1 byte
4 Display Information 4 1 byte
5 Display Information 5 1 byte
6 Boot Version of Module microcomputer. 3 byte
7 Program Version of Module microcomputer. 8 byte
8 Boot Version of ASTRA MANTA 3 byte
9 Program Version of ASTRA MANTA 8 byte
10 Sequence Version (43VIDEO) 4 byte
11 Sequence Version (43PC) 4 byte
12 Sequence Version (50VIDEO) 4 byte
13 Sequence Version (50PC) 4 byte
14
MAIN
, (comma) 1 byte
15 Product Infomation 1 1 byte
16 Product Infomation 2 1 byte
17 Product Infomation 3 1 byte
18 Product Infomation 4 1 byte
19 Version of IF microcomputer 4 byte
20 Version of Main microcomputer 8 byte
21 Boot Version of Main microcomputer 4 byte
22 Program Version of CARRERA-MANTA 8 byte
23 Boot Data Version of CARRERA-MANTA (DAT) 4 byte
24
GUI Data Version of CARRERA-MANTA (GUI-DAT)
8 byte
25
Enhanced Data Version of CARRERA-MANTA (WID-DAT)
8 byte
26
PIC Data Version of CARRERA-MANTA (PIC-DAT)
8 byte
Order Data Content Size Remarks
0 Received Command Name 3 byte 'QS6' only
All " 0 "
1 Version of DTB (PDP-436SXE only) 4 byte
2 Version of PC Card 8 byte
3
4
Version of Text 60 byte
User Passward 4 byte
Order Data Content Size Remark
1 Received Command Name 3 byte 'QMT' only
2 Temperature 3 byte
3 FAN Information 1 byte
0: STOP
1: MIN
2: MAX
