Pioneer PDP-436SXE Service Manual

PDP-436SXE
46
1234
1234
C
D
F
A
B
E
5. PCB PARTS LIST
77
77
LIST OF WHOLE PCB ASSEMBLIES
AWV2238 and AWV2239 are constructed the same except for the following :
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVXK5
PDP-436RXE
/WYVI5
1..R06 D-TUNER ASSY AWE1304 Not used Not used
1..OBE MAIN ASSY AWV2238 AWV2239 AWV2239
NSP 1..OBE FUKUGO ASSY AWV2237 AWV2237 AWV2237
2..AUDIO ASSY AWW1087 AWW1087 AWW1087
2..SR ASSY AWW1088 AWW1088 AWW1088
2..TUNER ASSY AWW1089 AWW1089 AWW1089
2..FRONT ASSY AWW1090 AWW1090 AWW1090
2..LED ASSY AWW1091 AWW1091 AWW1091
2..IR ASSY AWW1092 AWW1092 AWW1092
2..KEY ASSY AWW1093 AWW1093 AWW1093
2..PANEL SENSOR ASSY AWW1094 AWW1094 AWW1094
2..SUBPOWER ASSY AWW1095 AWW1095 AWW1095
1..OB DIGITAL ASSY AWV2244 AWV2244 AWV2244
NSP 1..PANEL CHASSIS (436) ASSY AWU1145 AWU1145 AWU1145
NSP
2..43 ADDRESS ASSY AWV2204 AWV2204 AWV2204
NSP
2..43 SCAN ASSY AWV2207 AWV2207 AWV2207
NSP
3..43 SCAN A ASSY AWW1018 AWW1018 AWW1018
NSP
3..43 SCAN B ASSY AWW1019 AWW1019 AWW1019
NSP 1..43 X DRIVE ASSY ASSY AWV2255 AWV2255 AWV2255
NSP
2..43 X DRIVE ASSY AWW1074 AWW1074 AWW1074
NSP
2..SUS CLAMP 1 ASSY AWW1022 AWW1022 AWW1022
NSP
2..SUS CLAMP 2 ASSY AWW1023 AWW1023 AWW1023
1..43 Y DRIVE ASSY AWV2256 AWV2256 AWV2256
> 1..POWER SUPPLY UNIT AXY1133 AXY1133 AXY1133
MAIN ASSY
Mark
Symbol and Description AWV2238 AWV2239
BOARD IF BLOCK
R4007 RS1/16SS0R0J Not used
R4008 Not used RS1/16SS0R0J
R4012 RS1/16SS101J Not used
CN4004 50P CONNECTOR AKM1201 Not used
CN4005 40P CONNECTOR AKM1217 Not used
AV SW BLOCK
Q4817, Q4819 2SC4116 Not used
Q4822, Q4823 2SA1586 Not used
C4881 CKSSYF104Z16 Not used
C4882, C4883 (10/16) DCH1165 Not used
R4942, R4943 RS1/16S182J Not used
