Pioneer PDP-436SXE Service Manual

PDP-436SXE
47
5678
56
7
8
C
D
F
A
B
E
R4953, R4968 RS1/16SS101J Not used
R4954, R4969 RS1/16S470J Not used
R4955, R4956 RS1/16S102J Not used
R4958, R4971 RS1/16SS102J Not used
R4957, R4970 RS1/16SS104J Not used
IFUCOM BLOCK
Q5005 DTA124EUA Not used
R5076 RS1/16SS202J Not used
R5079 RS1/16SS0R0J Not used
MAINUCOM BLOCK
IC5204
TC74VHC125FTS1 Not used
C5210 CKSSYF104Z16 Not used
R5231, R5243 RS1/16SS103J Not used
R5251 Not used RS1/16SS103J
Mark
Symbol and Description AWV2238 AWV2239
Mark No. Description Part No.
R06 D-TUNER ASSY (436SXE model only)
[TUNER BLOCK]
SEMICONDUCTORS
IC1001 STV0361L
IC1000 UPC3221GV
Q1001 2SC2412K
Q1002 DTC124EUA
Q1003,Q1004 RK7002
D1001 1SS355
>
D1000 SM15T6V8A
COILS AND FILTERS
L1002 LCYAR82J2520
F1001,F1003-F1010 FERRITE BEAD VTF1091
F1012-F1014 FERRITE BEAD VTF1091
F1100,F1101 FERRITE BEAD VTF1091
F1202-F1204 FERRITE BEAD VTF1091
F1000 SAW FILTER XTF1002
L1200 CHIP FERRITE BEAD XTX1001
L1004 CHIP FERRITE BEAD XTX1003
L1000 CHIP BALUN TRANS XTX1005
CAPACITORS
C1054 BCG1050
C1028,C1038,C1042,C1046,C1051 CCG1205
C1043,C1044 CCSRCJ3R0C50
C1020 CEHVKW100M16
C1019 CEHVKW100M50
C1004,C1055 CEHVKW101M6R3
C1010 CEHVKW2R2M50
C1102 CEHVKW331M6R3
C1018,C1027,C1029,C1050 CEHVKW470M16
C1056,C1057 CEHVKW470M16
C1015 CKSRYB102K50
C1013,C1021,C1040,C1041,C1045 CKSRYB103K50
C1001-C1003,C1017,C1022 CKSRYB104K16
C1025,C1026,C1030-C1035,C1037 CKSRYB104K16
C1039,C1049,C1053,C1058-C1062 CKSRYB104K16
C1036 CKSRYB105K10
RESISTORS
All Resistors RS1/16S###J
OTHERS
>
FU1200 CHIP FUSE (0.25A) XEK1003
X1100 CRYSTAL (27MHz) XSS1010
[DEMUX BLOCK]
SEMICONDUCTORS
IC2001 SN74LVU04APW
IC2000 STI5517DWAL
IC2002 TC74VHC08FTS1
Q2000 2SC4081
D2000 DA204U
D2002 HVU307
D2005,D2009 RB501V-40
D2001 UDZS8R2(B)
VA2002 AVR-M1608C120MT2AB
COILS AND FILTERS
F2000-F2003 FERRITE BEAD VTF1091
L2000 CHIP FERRITE BEAD XTX1003
CAPACITORS
C2014,C2016 CCSRCH100D50
C2000,C2026,C2030 CCSRCH101J50
C2009 CCSRCH330J50
C2011,C2012 CCSRCH390J50
C2007 CCSRCH471J50
C2032-C2034,C2036 CEHVKW470M16
C2008,C2017,C2020,C2021 CKSRYB102K50
C2013 CKSRYB105K10
C2001 CKSRYB471K50
C2002,C2003,C2005,C2006 CKSRYF104Z16
C2018,C2019,C2022-C2025,C2028 CKSRYF104Z16
C2035,C2037-C2041,C2043-C2045 CKSRYF104Z16
C2047,C2048 CKSRYF104Z16
C2015 CKSRYF105Z10
C2027,C2029,C2042,C2046 CKSRYF223Z50
C2004 CKSRYF474Z16
RESISTORS
R2010,R2018,R2042 RAB4C103J
R2070,R2071 RAB4CQ220J
Other Resistors RS1/16S###J
OTHERS
X2001 CRYSTAL ASS1172
X2000 CRYSTAL (27MHz) BSS1112
Mark No. Description Part No.
