Pioneer PDP-436SXE Service Manual

PDP-436SXE
48
1234
1234
C
D
F
A
B
E
[MEMORY BLOCK]
SEMICONDUCTORS
IC3000,IC3003 K4S281632F-UC75
COILS AND FILTERS
L3005 CHIP FERRITE BEAD XTX1001
L3003 CHIP FERRITE BEAD XTX1003
CAPACITORS
C3010 CEHVKW470M16
C3000,C3003,C3007,C3008,C3012 CKSRYF104Z16
C3017,C3020-C3022 CKSRYF104Z16
C3001,C3002,C3004,C3014,C3015 CKSRYF223Z50
C3018,C3019,C3023,C3024 CKSRYF223Z50
RESISTORS
R3004-R3014 RAB4CQ470J
Other Resistors RS1/16S###J
[AV BLOCK]
SEMICONDUCTORS
IC4000 CS4334-KS
IC4003 CS8406CZZ
IC4100 PCM1803DB
IC4002 RC4558D
IC4001 SN74LVU04APW
Q4001,Q4002 2SC4081
COILS AND FILTERS
F4000,F4100 CHIP FERRITE BEAD VTF1091
CAPACITORS
C4000,C4002 CCG1205
C4010,C4011,C4042 CCSRCH101J50
C4008,C4009 CCSRCH121J50
C4007,C4013 CCSRCH220J50
C4019,C4102-C4104,C4108-C4113 CEHVKW100M16
C4004 CEHVKW2R2M50
C4012,C4022,C4023,C4029,C4039 CEHVKW470M16
C4006 CKSRYB102K50
C4001,C4014,C4032,C4033,C4038 CKSRYB103K50
C4040,C4041 CKSRYB105K10
C4003,C4005,C4017,C4018,C4021 CKSRYF104Z16
C4024,C4043,C4105-C4107 CKSRYF104Z16
RESISTORS
R4042,R4045,R4046 RS1/16S2000F
Other Resistors RS1/16S###J
OTHERS
CN4000 40P CONNECTOR AKM1217
JA4000 OPTICAL OUT MODULE GP1FM513TZ
X4000 CRYSTAL (12.288MHz) XSS1006
[COMMON-INTERFACE BLOCK]
SEMICONDUCTORS
IC5001 CIMAXSP2L
IC5000 ST890CDR
IC5002 TC74LCX245FTS1
IC5003,IC5004 TC74LCX373FT
Q5000 2SC4081
Q5001 DTA143EUA
Q5002 DTC124EUA
Mark No. Description Part No.
CAPACITORS
C5005,C5100 CEHVKW470M16
C5001 CKSRYB105K10
C5003,C5004,C5006,C5008-C5013 CKSRYF104Z16
RESISTORS
R5014,R5019,R5022,R5024,R5030 RAB4CQ470J
R5032,R5036-R5038,R5045-R5050 RAB4CQ470J
Other Resistors RS1/16S###J
OTHERS
CN5000 PCMCIA CONNECTOR XKP1003
[POWER BLOCK]
SEMICONDUCTORS
IC6002 BA05FP
IC6003 FPF2002
IC6001 M5291FP
IC6200 TC74LCX245FTS1
Q6006 2SB1188
Q6100 2SC4081
Q6003,Q6005,Q6010 DTA143EUA
Q6001,Q6009,Q6011,Q6200 DTC124EUA
Q6008 TPC8209
D6003,D6100-D6102 1SS355
D6001 RSX201L-30
D6103 UDZS30(B)
COILS AND FILTERS
L6000 LCYAR82J2520
F6000 CHIP FERRITE BEAD VTF1091
L6001,L6100,L6101 XTH1001
CHIP INDUCTOR (33UH)
CAPACITORS
C6027 CCSRCH101J50
C6010 CCSRCH331J50
C6004 CEHVKW100M50
C6017,C6028,C6036,C6042,C6044 CEHVKW101M6R3
C6031 CEHVKW2R2M50
C6000,C6026,C6104-C6106 CEHVKW331M6R3
C6001,C6011,C6013-C6015,C6019 CEHVKW470M16
C6023,C6100 CEHVKW470M16
C6022 CKSRYB105K10
C6003,C6005,C6006,C6012,C6018 CKSRYF104Z16
C6020,C6021,C6025,C6029,C6030 CKSRYF104Z16
C6033,C6038,C6102,C6200 CKSRYF104Z16
C6002,C6035 CKSRYF223Z50
C6008,C6016 CKSRYF474Z16
RESISTORS
R6031 RAB4C221J
R6012-R6014 RAB4C2R2J
R6204,R6205 RAB4CQ101J
Other Resistors RS1/16S###J
OTHERS
CN6003 50P CONNECTOR AKM1236
CN6000 PHP CONNECTOR 12P AKM1298
Mark No. Description Part No.
