QNG: Returning data (logs keep on Main microcomputer) on shutdown of Main ASSY.
• Details on the NG data and subcategory
• Data on Subcategories for failure in 3-wire serial communication of Main microcomputer (subcategory 1)
Order
Data Size Context
0 Received Command Name 3 byte 'QNG' only
1 Latest NG data 1 byte
2 Data of subcategory for the latest NG 1 byte
3 Data of hour meter for the latest NG 7 byte
4 Data of temperature for the latest NG 3 byte
5 2nd latest NG data 1 byte
6 Data of subcategory for the 2nd latest NG 1 byte
7 Data of hour meter for the 2nd latest NG 7 byte
8 Data of temperature for the 2nd latest NG 3 byte
:: :
29 8th latest NG data 1 byte
30 Data of subcategory for the 8th latest NG 1 byte
31 Data of hour meter for the 8th latest NG 7 byte
32 Data of temperature for the 8th latest NG 3 byte
Data Cause of Shutdown Remarks
0 Normal
1 Failure of communication to Module microcomputer
2 3-wire Serial Communication of Main microcomputer. Subcategory ⇒ 1
3 IIC Communication failure of Main microcomputer Subcategory ⇒ 2
4 Communication failure of Main microcomputer &Unknown Error
5 Fan stopped
6 Abnormally high temperature
7 Failure of Digital Tuner Subcategory ⇒ 3
8 Abnormalilty in ASIC power line (DC-DC)
Data Cause of Shutdown Remarks
0 Non subcategory
1 Communication failure of IF microcomputer Power OFF
2 MANTA communication failure(MULIT1) Power OFF
3 MANTA communication failure(MULIT2) Reserved
4 MANTA communication failure(I/P)
5 MANTA communication failure(D-SEL)
