Pioneer PDP-436SXE Service Manual

PDP-436SXE
126
1234
1234
C
D
F
A
B
E
Front Shield Chassis
3
3
3
3
3
3
4
4
3
3
5
2
3
3
1
2
1
Detach the speaker cables from their cable ties.
2
Disconnect the one flexible cable.
3
Remove the nine screws.
4
Remove the two screws.
5
Remove the front shield chassis with the PCB boards.
Front Case Assy 43
4
1
Pull the lower part of the Front case Assy 43 toward you and out.
2
Remove the Front case Assy 43, by pulling it upward.
Front shield chassis
Front case Assy 43
FRONT Assy KEY Assy
1
