Pioneer PDP-436SXE Service Manual

PDP-436SXE
13
5678
56
7
8
C
D
F
A
B
E
(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-436SXE/WYVIXK5, PDP-436RXE/WYVIXK5 and WYVI5 are constructed the same except for the following:
Mark
No. Description Part No.
1 SR Assy AWW1088
2 LED Assy AWW1091
3• • • • •
4FRONT Assy AWW1090
5 KEY Assy AWW1093
6 Rear Case (436SX) ANE1648
7Terminal Label See Contrast table (2)
> 8 Cushion AED1288
9 Rear Case Cushion AEB1439
10 Bolt Caution Label See Contrast table (2)
NSP 11 Name Label See Contrast table (2)
12 Under Cover (436SX) ANE1649
13 Terminal Panel E See Contrast table (2)
> 14 AC Inlet (CN1) AKP1275
15 • • • • •
> 16 FFC Cushion AEB1442
17 Control Button (SX) AAC1556
18 4P Housing Wire (J126) ADX3206
19 Front Shield Chassis ANK1816
20 Wire Saddle AEC2031
21 8P Housing Wire (J127) ADX3207
22 Speaker Box Assy L AMW1006
23 Speaker Box Assy R AMW1007
NSP 24 Speaker (Tweeter) • • • • •
NSP 25 Speaker (Woofer) • • • • •
NSP 26 Speaker Box L • • • • •
NSP 27 Speaker Box R • • • • •
NSP 28 Speaker Buffle L • • • • •
NSP 29 Speaker Buffle R • • • • •
NSP 30 Serial Sheet AAX3143
NSP 31 Cushion • • • • •
NSP 32 Speaker Stay L • • • • •
NSP 33 Speaker Stay R • • • • •
NSP 34 Wire Saddle • • • • •
NSP 35 Insulation Bush • • • • •
NSP 36 Insulation Spacer • • • • •
NSP 37 Spacer • • • • •
38 Screw ABA1341
39 Screw (3 x 40P) ABA1332
40 Hex Head Screw ABA1345
41 Screw ABA1338
42 Screw ABA1340
43 Hexagon Screw BBA1051
44 Screw AMZ30P060FTB
45 Screw TBZ40P080FTB
46 Screw AMZ30P060FTB
47 Screw ABZ30P080FTB
48 Screw BBZ40P180FTB
49 Screw APZ30P100FTB
50 Screw BPZ30P080FTB
51 • • • • •
52 • • • • •
53 Screw BBB30P120FNI
54 • • • • •
NSP 55 Screw • • • • •
NSP 56 Screw • • • • •
NSP 57 Screw • • • • •
58 Screw AMZ30P080FTC
59 Screw ABA1322
NSP 60 4P Housing Wire (J201) • • • • •
NSP 61 4P Housing Wire (J101) • • • • •
62 Locking Wire Saddle AEC1948
NSP 63 Screw • • • • •
64 Washer WC40FTB
65 Protect sheet C AED1300
66 Protect sheet B AED1299
67 Protect sheet A AED1298
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVIXK5
PDP-436RXE
/WYVI5
7Terminal Label (SXE) AAX3241 Not used Not used
7Terminal Label (RXE) Not used AAL3240 AAL3242
10 Bolt Caution Label XE AAX3243 AAX3243 AAX3244
NSP 11 Name Label (436SXE) AAL2724 Not used Not used
NSP 11 Name Label (436RXE) Not used AAL2723 AAL2725
13 Terminal Panel E SXE ANC2385 Not used Not used
13 Terminal Panel E RXE Not used ANC2384 ANC2384
