(1) FRONT SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-436SXE/WYVIXK5, PDP-436RXE/WYVIXK5 and WYVI5 are constructed the same except for the following:
Mark
No. Description Part No.
1Front Case Assy 43 See Contrast table (2)
NSP 2 Front Case (436SX) AMB2875
3 Punching Sheet (L) See Contrast table (2)
4 Punching Sheet (R) See Contrast table (2)
5 Punching Sheet E (door) AAS1008
6Front Terminal Sheet E AAK2875
7 Door AAN1485
8• • • • •
9 Door Cushion AED1268
10 Catcher AEC2040
11 Pioneer Badge AAM1096
12 Gear Damper AXA1020
13 Screw APZ30P100FTB
NSP 14 LED Lens AAK2848
15 Panel Cushin V (43) AED1256
16 Panel Cushin H (43) AED1286
17 Blind Cushion (436SX) AEB1420
18 Power Button AAD4133
19 Coil Spring ABH1120
Mark No. Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVIXK5
PDP-436RXE
/WYVI5
1Front Case Assy 43SXE AMB2892 Not used Not used
1Front Case Assy 43RXE Not used AMB2891 AMB2891
3 Punching Sheet SXE (L) AAS1013 Not used Not used
3 Punching Sheet E (L) Not used AAS1005 AAS1005
4 Punching Sheet SXE (R) AAS1007 Not used Not used
4 Punching Sheet RXE (R) Not used AAS1006 AAS1006
