(1) CHASSIS SECTION (1/2) PARTS LIST
(2) CONTRAST TABLE
PDP-436SXE/WYVIXK5, PDP-436RXE/WYVIXK5 and WYVI5 are constructed the same except for the following:
Mark
No. Description Part No.
1 IR Assy AWW1092
>
2Power Switch (S1) ASG1092
3Power Housing Wire (43)(J103) ADX3291
>
4Fan Motor 80 x 25L AXM1052
5 Floating Rubber 80 AEB1427
6Fan Holder ANG2833
7 Sub Frame L Assy 436SX ANA1889
8 Sub Frame R Assy 436SX ANA1890
9 Wire Saddle AEC1745
10 Chassis Support AMR3475
11
Front Chassis H Assy 436SX
ANA1924
12 Panel Holder V1 (43) ANG2773
13 Panel Holder V2 (43) ANG2774
14 Front Chassis VL (436SX) AMA1018
15 Front Chassis VR (436SX) AMA1019
16 Panel Holder H (43) ANG2772
17 3P Housing Wire (J124) ADX3204
18 Screw ABA1341
19 Screw TBZ40P080FTB
20 Screw AMZ30P060FTB
21 Screw APZ30P080FTB
22 Screw ABZ30P080FTC
23 Screw VBB30P080FNI
24 Screw BPZ30P080FTB
25 Screw BBZ30P060FTC
26 Screw APZ30P100FTB
27 Waterproof Cushion AEB1424
28 Binder See Contrast table (2)
29 Insulation Sheet AED1289
>
30 Gasket AV ANK1817
31 Re-use Clamp AEC2083
32 Ferrite Core See Contrast table (2)
33 Ferrite Core Holder See Contrast table (2)
34 Cushion See Contrast table (2)
Mark No. Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVIXK5
PDP-436RXE
/WYVI5
28 Binder Not used AEC-093 AEC-093
32 Ferrite Core ATX1060 Not used Not used
33 Ferrite Core Holder AEC1818 Not used Not used
34 Cushion Not used Not used AEB1441
