PDP-436SXE
21
5678
56
7
8
C
D
F
A
B
E
(1) AV BLOCK PARTS LIST
(2) CONTRAST TABLE
PDP-436SXE/WYVIXK5, PDP-436RXE/WYVIXK5 and WYVI5 are constructed the same except for the following:
Mark
No. Description Part No.
1 R06 D-TUNER Assy See Contrast table (2)
2 OBE MAIN Assy See Contrast table (2)
3AUDIO Assy AWW1087
4 TUNER Assy AWW1089
5 Flexible Cable (J208) ADD1340
6 Flexible Cable (J210) See Contrast table (2)
7 Flexible Cable (J211) See Contrast table (2)
8 Flexible Cable (J212) ADD1337
9 12/16P Housing Wire (J129) See Contrast table (2)
10 9P Housing Wire (J130) ADX3261
11 13P Housing Wire (J131) ADX3211
12 8P Housing Wire (J132) ADX3212
13 AV Base Chassis E ANA1902
14 Tuner Prop E AND1194
15 Frontend Base ANG2868
16 Frontend Shield ANG2935
17 Rear Cover See Contrast table (2)
18 Spacer AEC1256
>
19 Gasket N See Contrast table (2)
20 Gasket A ANK1811
21 Gasket B ANK1812
22 Gasket C ANK1813
>
23 Gasket XE ANK1818
24 Clamp AEC1884
25 Card Spacer AEC1957
26 Locking Card Spacer AEC1801
27 Locking Card Spacer AEC2019
28 Terminal Support See Contrast table (2)
29 • • • • •
30 • • • • •
31 Screw PMB30P080FNI
32 Screw AMZ30P060FTB
33 Screw See Contrast table (2)
34 Screw See Contrast table (2)
35 Screw See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-436SXE
/WYVIXK5
PDP-436RXE
/WYVIXK5
PDP-436RXE
/WYVI5
1 R06 D-TUNER Assy AWE1304 Not used Not used
2 OBE MAIN Assy AWV2238 AWV2239 AWV2239
6 Flexible Cable (J210) ADD1335 Not used Not used
7 Flexible Cable (J211) ADD1341 Not used Not used
9 12P/16P Housing Wire (J129) ADX3277 Not used Not used
9 16P Housing Wire (J129) Not used ADX3260 ADX3260
17 Rear Cover AMR3425 Not used Not used
>
19 Gasket N ANK1776 Not used Not used
28 Terminal Support Not used ANG2869 ANG2869
33 Screw ABA1341 ABA1341 ABA1335
34 Screw BBZ30P060FTB Not used Not used
35 Screw AMZ30P080FTC Not used Not used
To Next Page
