Pioneer PDP-436SXE Service Manual

PDP-436SXE
50
1234
1234
C
D
F
A
B
E
C4607, C4611, C4617, C4619, C4624 CCG1205
C4628, C4643, C4649 (2.2/10) CCG1205
C4618 CEHAT471M10
C4606, C4608, C4609, C4612 CKSRYB105K10
C4615, C4616, C4626, C4629 CKSRYB105K10
C4631-C4633, C4641, C4642 CKSRYB105K10
C4645, C4646, C4650, C4652-C4654 CKSRYB105K10
C4661-C4663 CKSRYB105K10
C4610, C4613, C4627, C4630 CKSSYB102K50
C4647, C4648 CKSSYB102K50
>
C4671-C4676 CKSSYB102K50
C4604, C4614, C4622, C4637, C4651 CKSSYF104Z16
C4603, C4625, C4638 (10/16) DCH1165
RESISTORS
R4608, R4670, R4696 RS1/10S121J
R4601, R4644, R4645, R4658, R4686 RS1/10S151J
R4734, R4735 RS1/10S151J
R4630-R4632, R4643, R4675, R4681 RS1/16S75R0F
R4715-R4717, R4733, R4740-R4742 RS1/16S75R0F
R4602, R4603, R4605, R4610-R4612 RS1/16S###J
R4614-R4616, R4621-R4623, R4626 RS1/16S###J
R4635, R4636, R4639-R4641, R4646 RS1/16S###J
R4648-R4650, R4656, R4657, R4660 RS1/16S###J
R4661, R4662, R4664, R4665, R4667 RS1/16S###J
R4668, R4672, R4684, R4685, R4690 RS1/16S###J
R4691, R4693, R4694, R4697-R4699 RS1/16S###J
R4709-R4711, R4721, R4736, R4737 RS1/16S###J
R4738, R4739 RS1/16S###J
Other Resistors RS1/16SS###J
OTHERS
JA4604 2P VERTICAL PIN JACK AKB1331
JA4605 PINJACK AKB1333
JA4601-JA4603 RGB CONNECTOR AKP1295
[AV SW BLOCK]
SEMICONDUCTORS
IC4805 NJM12904V
IC4806 R2S11001FT
IC4804 R2S11002FT
Q4801, Q4802, Q4804-Q4806, Q4809 2SA1586
Q4818, Q4820, Q4822, Q4823 2SA1586
Q4812, Q4813, Q4817, Q4819 2SC4116
Q4814 DTA124EUA
Q4815 DTC124EUA
Q4807 HN1B04FU
D4802 1SS301
D4801 1SS355
CAPACITORS
C4916 (4.7/10) ACG1122
C4821, C4835, C4871, C4875 (10/6.3) ACG7046
C4877, C4880 CCSRCH181J50
C4859 CCSRCH331J50
C4861 CCSRCH680J50
C4885, C4888 CCSRCH681J50
C4822, C4862 CEHVKW101M6R3
C4802, C4805, C4806, C4808 CKSRYB105K10
C4813, C4814, C4820, C4833, C4834 CKSRYB105K10
C4836, C4838-C4841, C4847, C4848 CKSRYB105K10
Mark No. Description Part No.
C4850, C4851, C4878, C4879 CKSRYB105K10
C4899-C4905 CKSRYB105K10
C4837 CKSRYB474K10
C4853-C4858, C4860, C4865 CKSSYB103K16
C4869, C4870, C4890-C4893 CKSSYB103K16
C4950-C4954 CKSSYB103K16
C4807, C4809 CKSSYB104K10
C4801, C4819, C4845, C4846, C4864 CKSSYF104Z16
C4873, C4881, C4884, C4886, C4887 CKSSYF104Z16
C4917-C4920, C4924, C4925 CKSSYF104Z16
C4844, C4863, C4866, C4872, C4876 DCH1165
C4882, C4883 (10/16) DCH1165
RESISTORS
R4784, R4786 RS1/16S1800F
R4785, R4787, R4792, R4794, R4796 RS1/16S5600F
R4791, R4793, R4795 RS1/16S75R0F
R4857-R4860, R4944, R4985 RS1/16SS3301F
R4921, R4925-R4927, R4933, R4942 RS1/16S###J
R4943, R4950, R4954-R4956, R4965 RS1/16S###J
R4966, R4967, R4969 RS1/16S###J
Other Resistors RS1/16SS###J
[IFUCOM BLOCK]
SEMICONDUCTORS
IC5002 HD64F3684FP
IC5003 PST9230N
IC5001 TC74VHC08FTS1
IC5004 TC7W126FU
Q5005 DTA124EUA
CAPACITORS
C5007, C5008 CCSSCH180J50
C5001 CEHVKW101M6R3
C5010 CKSSYB472K25
C5002-C5005, C5009, C5012 CKSSYF104Z16
RESISTORS
R5002, R5004, R5025, R5026 RAB4CQ103J
Other Resistors RS1/16SS###J
OTHERS
X5002 (9.830MHz) CERAMIC ASS1168
X5001 (32.768kHz) CRYSTAL ASS1172
[MAINUCOM BLOCK]
SEMICONDUCTORS
IC5202 BR24L64F-W
IC5206 MB91305PMC-G-BND
IC5207 MBM29DL162TE70TN
IC5209 PQ200WNA1ZPH
IC5213 PST3610UR
IC5212 PST3616UR
IC5203, IC5211 PST3628UR
IC5201, IC5204 TC74VHC125FTS1
Q5202 2SJ461A
Q5204 DTC124EUA
Q5201, Q5203 SM6K2
D5203 1SS355
D5201 SML-311UT
CAPACITORS
C5235 CCSRCH221J50
Mark No. Description Part No.
