4. TEMPERATURE
TEMP2 : The value read from the temperature sensor is displayed in the range of
000-255. Sensor Temperature (°C) = -0.57 x TEMP2 + 120.33
(When the sensor temperature exceeds over 60°C, SD process stats.)
FAN : The value of the Fan rotating state is displayed.
STOP: stopped, MIN: slow speed, MAX: high speed
1
123456789
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
I
TEMPE ERATUR
N F O R M A T I O N
ETMP2 130:
MIN:FAN
– 1 1V D 1 6 0 1 – N T V – J H S 6
This displays the internal set temperature and fan rotating state.
