PDP-436SXE
72
1234
1234
C
D
F
A
B
E
No. Display
Content
1 FAN <=>
Control FAN speed for Force.
2 DTB ANT VOLT <=>
Change the power supply voltage for DTB antenna.
RS-232C
–
–
2 FUNCTION CHECK
3 COMMON ADJ. mode
¶ Operation items
RGB1
Only for the technical use.
4 PANEL FACTORY mode
¶ Operation items
No. Function / Display
1 PANEL INFORMATION
2 PANEL WORKS
3 POWER DOWN
4 SHUT DOWN
5 PANEL-1 ADJ ( + )
6 PANEL-2 ADJ ( + )
7 PANEL REVICE ( + )
8 ETC. ( + )
9 MASK SETUP ( + )
Summary Descuiption
Display DIGITAL Assy software version and backup state, etc.
Display pulse meter and hour meter, etc.
Display power-down history.
Display shut-down history Module u-com detecting
Adjust sustain wave form and drive power.
Adjust panel white balance and ABL.
Set the correction level for panel degradation.
Act as copying back-up data and cleaing various data.
Display the asc screen.
RS - 232C
–
–
–
–
–
–
–
–
–
To Next Page
