PDP-436SXE

1234

• Commands that are effective during normal operation will also be effective during FAY (PFY) mode.

Note:

• The functions shown below will be forcibly switched when Mask ON/OFF is switched. (Even if the panel is off, changed

settings will be retained.)

While the status of Mask ON or OFF is maintained, if settings for the individual functions shown in 1 and 2 are changed,

those settings are retained (even if the drive frequency is changed).

1 Functions related to picture quality

Function Setting while Mask is ON Setting while Mask is OFF Remarks

Peripheral luminance correction OFF ON

WB correction interlocked with APL OFF ON

Streaking correction OFF ON

2 Functions related to panel protection

Function Setting while Mask is ON Setting while Mask is OFF Remarks

Detection of still picture OFF ON

Detection of cracking in the panel OFF ON

Scanning protection OFF ON

7 Setting for Factory mode permission/prohibition • • • [FAY/FAN] [PFY/PFN]

The commands FAY/FAN and PFY/PFN are for prohibiting/permitting panel-adjustment commands during normal operation

and are to be used to avoid accidental change of panel adjustment values.

Command

Format

Operation

Remarks

Effective Operation

Modes

Control (by the

microcomputer itself)

[FAY]

Normal operation mode

while the power is on

Adjustment mode: ON

Mask indications will be forcibly turned off.

[PFY] With a PFY command, the mask does not change.

[FAN]

During FAY Adjustment mode: OFF

[PFN]

• Depending on the type of mask displayed, phosphor burn of the panel may occur. As the panel-protection function is

forcibly turned off with this model, care must be taken when color-bar signals are to be displayed for an extended period.
