(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-506PE/WYVI and PDP-506PU/KUCXC are constructed the same except for the following:
Mark
No. Description Part No.
> 1AC Inlet AKP1274
2 Control Plate AND1185
3 Rear Case (506) ANE1639
4 Inner Grip Assy AMR3434
5AC Cushion AEC2035
NSP 6 Model Label See Contrast table (2)
7 Caution Label See Contrast table (2)
8AC Label PE See Contrast table (2)
9• • • • •
10 • • • • •
11 Screw (3 x 40P) ABA1332
12 Hexagon Head Screw BBA1051
13 Screw PMZ26P060FTB
14 Screw BPZ30P080FTB
15 Screw AMZ30P060FTB
16 Screw TBZ40P080FTB
Mark No. Symbol and Description PDP-506PE/WYVI PDP-506PU/KUCXC
NSP 6 Model Label (506PE) AAL2661 Not used
NSP 6 Model Label (506PU) Not used AAL2679
7 Caution Label AAX3117 AAX3075
8AC Label PE AAX3194 Not used
