PDP-506PE
58
1234
1234
C
D
F
A
B
E
6.3 METHOD FOR REPLACING THE SERVICE PANEL ASSY
(Rear of the Panel)
AWU∗∗∗∗
Vofs = 35V Vyprst = 270V
Hour Meter HSpace
AWU∗∗∗∗
Vofs = 35V Vyprst = 270V
Hour Meter H1520
Write in the value for the hour
meter when the Panel is
replaced (ex. 1520H).
A.PNEL
L/1
[
BT60VS
]
V–D1 1 1160 NTV HJ–S6FACT
AJ(+)PNEL1AD
1
5
10
15
16
15 10 15 20 25 30 32
A.PNEL
L/1
[
BT60VS
]
V–D1 1 1160 NTV HJ–S6FACT
O <=>VLRSTP
AJPNEL1AD
5:0 8
1
5
10
15
16
15 10 15 20 25 30 32
When the Panel Assy is replaced with one for service, the following adjustments are required:
Adjustments of Vofs voltage and Vyprst voltage
Enter the reference adjustment values for the Vofs voltage and Vyprst voltage that are written on the label attached to the
panel for service.
Note: Enter the values, using an RS-232C command or the Factory Menu.
Using an RS-232C command
Enter a "PFY" command with Factory mode ON.
Convert the adjustment voltage values written on the label attached at the rear of the Panel to an input command, referring to
the conversion chart. (See the next page.)
• Reference adjustment of the Vofs voltage: Ex. "Vofs = 35" (Check the conversion chart.) Enter "VOF112."
• Reference adjustment of the Vyprst voltage: Ex. 50-inch "Vyprst = 270 V" (Check the conversion chart.) Enter "VRP055."
(Note that the conversion charts for 50-inch and 43-inch Panels are different.)
Clearing data on various histories of the Panel, such as those on the hour meter
It is necessary to clear the data on the hour meter, etc. to match them to the actual driving hours of the Panel.
It is also necessary to clear the data on SD and PD, because the accumulated power-on time when a shutdown or power-
down occurred is recorded.
Note: Clear the values, using an RS-232C command or the Factory Menu.
There are two types of hour meters. Do not take the MR hour meter for the hour meter.
Using an RS-232C command
To acquire the accumulated power-on time of the product itself, use the "GS2" RS-232C command.
1 To clear the data on the hour meter (for the Panel) : CHM
2 To clear the data on the pulse meter : CPM
3 To clear the data on the SD history : CSD
4 To clear the data on the PD history : CPD
Using the Factory Menu
Using the Factory Menu
Select the main item "PANEL FACT." by pressing the MUTE key then enter Panel Factory mode by pressing the SET key.
Using the 5/ keys, select "PANEL-1 ADJ" then press the SET key to enter the next lower nested layer.
Select "VOL-OFFSET" or "VOL RST P" then enter a command value converted from the voltage value, using the 2/3 keys.
See "7.1.7 HOW TO CLEAR HISTORY DATA."
