5. PCB PARTS LIST
77
77
LIST OF WHOLE PCB ASSEMBLIES
AWW1075 and AWW1020 are constructed the same except for the following :
AWV2258 and AWV2210 are constructed the same except for the following :
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark Symbol and Description
PDP-506PE
/WYVI
PDP-506PU
/KUCXC
NSP 1..PANEL CHASSIS (506) ASSY AWU1143 AWU1143
NSP 2..50 ADDRESS ASSY AWV2208 AWV2208
NSP 2..50 SCAN ASSY AWV2211 AWV2211
NSP 3..50 SCAN A ASSY AWW1026 AWW1026
NSP 3..50 SCAN B ASSY AWW1027 AWW1027
NSP 1..50 X DRIVE ASSY AWV2257 AWV2209 or AWV2257
2..50 X DRIVE ASSY AWW1075 AWW1020 or AWW1075
2..SUS CLAMP 1 ASSY AWW1022 AWW1022
2..SUS CLAMP 2 ASSY AWW1023 AWW1023
1..50 Y DRIVE ASSY AWV2258 AWV2210 or AWV2258
NSP 1..HD DIGITAL ASSY AWV2202 AWV2202
2..HD DIGITAL ASSY AWW1028 AWW1028
2..HD LED ASSY AWW1029 AWW1029
2..HD IR ASSY AWW1030 AWW1030
1..HD AUDIO ASSY AWV2203 AWV2203
> 1..POWER SUPPLY UNIT AXY1112 AXY1112
50 X DRIVE ASSY
Mark Symbol and Description AWW1075 AWW1020
IC1101 AXF1142 AXF1155
C1101 ACG1112
(0.22U/250V)
ACG1088
(0.1U/250V)
C1106-C1110 Not used ACE1178
C1112, C1113 (0.22U/250V) ACG1112 Not used
C1161-C1164, C1166 ACE1168 Not used
C1297, C1298 (3300p/630V) ACG1129 Not used
50 Y DRIVE ASSY
Mark Symbol and Description AWV2258 AWV2210
IC2101 AXF1142 AXF1155
C2103 ACG1112
(0.22U/250V)
ACG1088
(0.1U/250V)
C2107, C2108 (0.22U/250V) ACG1112 Not used
C2131-C2134, C2136 ACE1168 ACE1178
C2271 ACG1124
(0.1U/100V)
ACG1118
(0.33U/100V)
C2272 (0.1U/100V) ACG1124 Not used
