PCB PARTS LIST FOR PDP-506PE/WYVI UNLESS OTHER WISE NOTED
Mark No. Description Part No.
50 ADDRESS ASSY
[50 ADR LOGIC BLOCK]
SEMICONDUCTORS
IC1501 PEE002A
COILS AND FILTERS
L1504 CHIP SOLID INDUCTOR QTL1013
CAPACITORS
C1501,C1502 CKSRYB105K6R3
C1509,C1510 CKSSYB102K50
C1503-C1507,C1551-C1555 CKSSYF104Z16
RESISTORS
R1530,R1531 RS1/16S0R0J
R1505-R1509 RS1/16SS1000F
Other Resistors RS1/16SS###J
OTHERS
CN1501 40P CONNECTOR AKM1217
CN1502 PH CONNECTOR 4P AKM1290
[50 ADR RESONANCE BLOCK]
SEMICONDUCTORS
IC1601,IC1602 TND307TD
Q1613 2SA1163
Q1614-Q1616 HAT1110R
Q1606,Q1608,Q1611 QSZ2
Q1612 RN1901
Q1601-Q1605 SP8M41
D1612 1SS302
D1625-D1629 1SS355
D1631-D1650 EP05FA20
D1601,D1605,D1607,D1610,D1613 UDZS15(B)
D1616,D1620,D1622 UDZS15(B)
COILS AND FILTERS
L1601-L1605 SMD COIL ATH1163
CAPACITORS
C1609 (0.1U/100V) ACG1098
C1601,C1606,C1610 (0.068U/100V) ACG1123
C1611,C1614 (0.068U/100V) ACG1123
C1602-C1605 (56UF/80V) ACH1405
C1613 CKSRYB104K25
C1619 CKSYB105K16
RESISTORS
R1606,R1611,R1613,R1621 RS1/16SS###J
Other Resistors RS1/16S###J
50 SCAN A ASSY
SEMICONDUCTORS
IC2701-IC2706 AN16025A
D2701-D2707 1SS355
CAPACITORS
C2701,C2711,C2721 (0.1U/250V) ACG1088
C2731,C2741,C2751 (0.1U/250V) ACG1088
C2710,C2720,C2730,C2740,C2750 CCSRCH181J50
C2760 CCSRCH181J50
C2708,C2709,C2718,C2719 CCSRCH331J50
C2728,C2729,C2738,C2739 CCSRCH331J50
C2748,C2749,C2758,C2759 CCSRCH331J50
C2705-C2707,C2715-C2717 CCSRCH390J50
C2725-C2727,C2735-C2737 CCSRCH390J50
C2745-C2747,C2755-C2757 CCSRCH390J50
C2703,C2713,C2723,C2733,C2743 CKSRYB105K6R3
C2753 CKSRYB105K6R3
RESISTORS
R2705,R2710,R2713,R2716,R2719 RAB4C221J
R2722 RAB4C221J
Other Resistors RS1/16S###J
OTHERS
CN2702 PH CONNECTOR 3P AKM1274
CN2701 13P BRIDGE CONNECTOR AKP1261
50 SCAN B ASSY
SEMICONDUCTORS
IC2801-IC2806 AN16025A
IC2807 TC7SH08FUS1
D2801-D2807 1SS355
CAPACITORS
C2801,C2811,C2821 (0.1U/250V) ACG1088
C2831,C2841,C2851 (0.1U/250V) ACG1088
C2810,C2820,C2830,C2840,C2850 CCSRCH181J50
C2860 CCSRCH181J50
C2808,C2809,C2818,C2819 CCSRCH331J50
C2828,C2829,C2838,C2839 CCSRCH331J50
C2848,C2849,C2858,C2859 CCSRCH331J50
C2805-C2807,C2815-C2817 CCSRCH390J50
C2825-C2827,C2835-C2837 CCSRCH390J50
C2845-C2847,C2855-C2857 CCSRCH390J50
C2803,C2813,C2823,C2833,C2843 CKSRYB105K6R3
C2853,C2861 CKSRYB105K6R3
RESISTORS
R2803,R2808,R2811,R2814,R2817 RAB4C221J
R2820 RAB4C221J
Other Resistors RS1/16S###J
OTHERS
CN2802 PH CONNECTOR 3P AKM1274
CN2801 13P BRIDGE CONNECTOR AKP1261
50 X DRIVE ASSY
[50X LOGIC BLOCK]
SEMICONDUCTORS
IC1001 TC74ACT541FT
IC1002 TC74VHC00FTS1
