(1) CHASSIS SECTION (2/2) PARTS LIST
(2) CONTRAST TABLE
PDP-506PE/WYVI and PDP-506PU/KUCXC are constructed the same except for the following:
Mark
No. Description Part No.
1 50 X DRIVE Assy See Contrast table (2)
2 SUS CLAMP 1 Assy AWW1022
3 SUS CLAMP 2 Assy AWW1023
4 50 Y DRIVE Assy See Contrast table (2)
5 HD DIGITAL Assy AWW1028
6 HD AUDIO Assy AWV2203
>
7POWER SUPPLY Unit AXY1112
8 Ring Core with Case ATX1042
9Ferrite Core ATX1048
10 Flexible Cable (J201) ADD1293
11 Flexible Cable (J202) ADD1294
12 Flexible Cable (J203) ADD1295
13 Flexible Cable (J204) ADD1296
14 Flexible Cable (J205) ADD1297
15 Flexible Cable (J206) ADD1298
16 4P Housing Wire (J108) ADX3117
17 6P Housing Wire (J109) See Contrast table (2)
18 12P Housing Wire (J110) See Contrast table (2)
19 6P Housing Wire (J111) ADX3120
20 3P Housing Wire (J113) See Contrast table (2)
21 14P Housing Wire (J104) ADX3158
22 3P Housing Wire (J105) ADX3159
23 9P Housing Wire (J101) ADX3186
24 8P Housing Wire (J102) ADX3187
25 5P Housing Wire (J106) ADX3188
26 6P Housing Wire (J107) ADX3189
27 Conductive Plate XA ANG2776
28 FC Stay ANG2815
29 Binder AEC-093
NSP 30 PCB Spacer AEC1188
31 Flat Clamp AEC1879
32 PCB Spacer AEC1941
33 Drive Silicone Sheet AEH1095
34 Power Supply Insulation Sheet AMR3447
35 Audio Insulation Sheet AMR3469
36 Wire Saddle AEC1745
NSP 37 Address Sheet AMR3491
38 • • • • •
39 Screw ABA1324
40 Screw PMB30P060FTC
41 Screw VBB30P080FNI
Mark
No. Description Part No.
Mark No. Symbol and Description PDP-506PE/WYVI PDP-506PU/KUCXC
1 50 X DRIVE Assy AWW1075 AWW1020 or AWW1075
4 50 Y DRIVE Assy AWV2258 AWV2210 or AWV2258
17 6P Housing Wire (J109) ADX3118 ADX3132
18 12P Housing Wire (J110) ADX3119 ADX3133
20 3P Housing Wire (J113) ADX3122 ADX3136
