Pioneer PDP-506PG User Manual

PDP-506PE
36
1234
1234
C
D
F
A
B
E
SUS CLAMP 1 ASSY
SEMICONDUCTORS
D1631 DF20L60U
CAPACITORS
C1632 ACE1179
OTHERS
KN1632 GROUND PLATE ANK-142
CN1631 3P TOP POST B3B-EH
KN1631 WRAPPING TERMINAL VNF1084
SUS CLAMP 2 ASSY
SEMICONDUCTORS
D1641 DF20L60U
CAPACITORS
C1642 ACE1179
OTHERS
KN1642 GROUND PLATE ANK-142
CN1641 3P TOP POST B3B-EH
KN1641 WRAPPING TERMINAL VNF1084
50 Y DRIVE ASSY
[50Y LOGIC BLOCK]
SEMICONDUCTORS
IC2002 TC74ACT540FT
IC2001,IC2004 TC74ACT541FT
IC2003,IC2005 TC74VHC08FTS1
CAPACITORS
C2003 CEHAT470M16
C2001,C2002,C2004-C2006 CKSSYB104K10
RESISTORS
R2003,R2006 RAB4C101J
R2001,R2002,R2017,R2021 RAB4C470J
R2004,R2005,R2019,R2020 RAB4C472J
Other Resistors RS1/16S###J
OTHERS
CN2001 40P CONNECTOR AKM1217
[50Y RESONANCE BLOCK]
SEMICONDUCTORS
IC2101 AXF1142
IC2141 BA10393F
Q2141 2SC4081
D2101-D2105 D1FL40
COILS AND FILTERS
L2103,L2104 CHOKE COIL ATH1119
L2101,L2102 CHOKE COIL ATH1187
L2105,L2106 CHOKE COIL ATH1187
CAPACITORS
C2131-C2134,C2136 (3.3U/250V) ACE1168
C2103,C2107,C2108 (0.22U/250V) ACG1112
C2104 (470p/630V) ACG1126
C2106 CCG1186
C2101,C2145 CKSRYB105K6R3
Mark No. Description Part No.
C2141,C2143,C2144 CKSSYB104K10
C2102 CKSYB105K25
RESISTORS
R2101 ACN1174
R2142,R2143 RS1/10S1003F
R2103,R2107 RS1/10S104J
R2146,R2149 RS1/16S5601F
R2147,R2151 RS1/16S6801F
R2102 RS2MMF100J
R2108 RS3LMF100J
Other Resistors RS1/16S###J
[50Y SUS BLOCK]
SEMICONDUCTORS
IC2252,IC2253 AXF1141
IC2350 MM1565AF
IC2250 PS9117
IC2231,IC2251 TND301S
IC2203,IC2221 TND307TD
Q2202 2SA2142
Q2250 2SC4081
Q2290 2SK3050
Q2221 2SK3325-Z
Q2280,Q2281 2SK3399
D2233 1SS301
D2213 1SS302
D2203,D2212,D2351 1SS355
D2202,D2204,D2205,D2234 CRH01
D2251,D2252,D2272 CRH01
D2211 D1FK60
D2232,D2271 UDZS16(B)
D2250 UDZS5R6(B)
COILS AND FILTERS
L2353 INDUCTOR ATH1186
F2301-F2320 FERRITE BEAD ATX1055
F2352 INDUCTOR CTF1449
L2350,L2351,L2354 LFEA100J
CAPACITORS
C2330,C2335,C2341,C2342 ACE1178
C2231 (0.33U/100V) ACG1118
C2271,C2272 (0.1U/100V) ACG1124
C2336,C2337 ACH1423
C2270 ACH1426
C2226 ACH1427
C2207 CCSRCH102J50
C2355,C2369 CEHAT101M10
C2357 CEHAT470M16
C2208,C2221,C2339,C2364 CEHAT470M25
C2356 CKSRYB104K16
C2353,C2358,C2359 CKSRYB105K6R3
C2363 CKSRYB473K16
C2209,C2222,C2230,C2252 CKSRYF104Z50
C2250 CKSSYB104K10
C2354,C2360 CKSYB105K25
Mark No. Description Part No.
