Pioneer PDP-506PG User Manual

PDP-506PE
40
1234
1234
C
D
F
A
B
E
OTHERS
CN3752 12P PH CONNECTOR AKM1335
3771 AUDIO HEATSINK ANH1636
CN3751 3P TOP POST (VH) B3P-VH
3772-3775 SCREW VBB30P100FNI
KN3751 WRAPPING TERMINAL VNF1084
KN3752 WRAPPING TERMINAL VNF1084
[ST TERMINAL BLOCK]
COILS AND FILTERS
>
L3901,L3902 LINE FILTER ATF1206
CAPACITORS
>
C3906,C3908,C3914,C3916 CCSRCH101J50
C3903,C3911 CKSRYB332K50
C3904,C3912 CKSRYF473Z50
RESISTORS
R3901-R3904 RD1/2MMF100J
OTHERS
JA3901 SPEAKER TERMINAL AKE1061
POWER SUPPLY UNIT
POWER SUPPLY Unit has no service part.
Mark No. Description Part No.
