Pioneer PDP-506PG - Acquisition of PD logs ••• [QPD]

PDP-506PE
53
5678
56
7
8
C
D
F
A
B
E
Data Arrangement
Data
Length
Output Example
ECO 3Byte QPD
1 Latest "1st PD" data 1byte A
2 Latest "2nd PD" data 1byte 2
3 Data from the hour meter for the latest PD 8byte 00010020
4 Second latest "1st PD" data 1byte E
5 Second latest "2nd PD" data 1byte 9
6 Data from the hour meter for the second latest PD 8byte 00008523
7 Third latest "1st PD" data 1byte 4
8 Third latest "2nd PD" data 1byte 3
9 Data from the hour meter for the third latest PD 8byte 00004335
10 Fourth latest "1st PD" data 1byte 2
11 Fourth latest "2nd PD" data 1byte 0
12 Data from the hour meter for the fourth latest PD 8byte 00000945
13 Fifth latest "1st PD" data 1byte 4
14 Fifth latest "2nd PD" data 1byte 0
15 Data from the hour meter for the fifth latest PD 8byte 00000715
16 Sixth latest "1st PD" data 1byte A
17 Sixth latest "2nd PD" data 1byte 2
18 Data from the hour meter for the sixth latest PD 8byte 00000552
19 Seventh latest "1st PD" data 1byte A
20 Seventh latest "2nd PD" data 1byte 0
21 Data from the hour meter for the seventh latest PD 8byte 00000213
22 Eighth latest "1st PD" data 1byte D
23 Eighth latest "2nd PD" data 1byte 0
24 Data from the hour meter for the eighth latest PD 8byte 000001A7
CS 2Byte 27
¶ PD data
0 No PD
1 Not used
2 P-POWER
3 SCAN
4 SCN-5V
5 Not used
6 Y-DCDC
7 Y-SUS
8 Address
9 X-DRIVE
A X-DCDC
B X-SUS
C DIG-DCDC
D QS (driving stopped)
E Not used
F Specification inability
Command
Format
Effective Operation
Modes
Function Remarks
[QPD] All operations To acquire data on the power-down logs Return data: 3 (ECO)+80(DATA)+2(CS)=85Byte
7 Acquisition of PD logs • • • [QPD]
The command QPD is for acquiring data from the 8 latest power-down (PD) logs.
