Pioneer PDP-6071PU User Manual

PDP-6071PU
112
1234
1234
C
D
F
A
B
E
×3
5
Rear Case (607)
2
1
1
2
4
3
3
1
Remove the two screws.
2
Remove the function button panel.
3
Remove the two screws.
4
Remove the side input cover.
Function button panel
Side input cover
SIDE KEY Assy
Function button panel
Side input cover
1
Remove the six screws. (PMB30P100FTB)
2
Remove the sub frame covers L and R.
3
Remove the four screws. (PMB40P120FTB)
4
Remove the two handles.
5
Remove the 40 screws. (AMZ30P060FTB)
6
Remove the six screws. (APZ40P100FTB)
7
Remove the one screw. (ABA1341)
8
Remove the rear case (607).
Sub frame cover L and R
Handle
Rear case (607)
Rear case (607)
Handle HandleSub frame cover L Sub frame cover R
8
5
5
5 5 5
55
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
1
1
2
4 4
2
1
1
1
1
3
3
3
3
×11
5
×3
5
×3
6
×3
6
7
