THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
1F15
7-10-00
JACKING
Jacking the airplane is necessary to service the landing gear and other operations. The jacking operation
can be performed by using tripod jacks; in other situations (i.e. - emergency, post-accident lifting, etc.),
slings or air bags should be used.
If wing or fuselage shoring is required, make sure the support is contoured to conform to the surface it is
supporting.
Jacking
A. Align jacks under the wing respective pads on the wing front spar.
CAUTION: BE SURE TO APPLY SUFFICIENT SUPPORT BALLAST. OTHERWISE, THE
AIRPLANE WILL SLIP FORWARD AND FALL ON THE FUSELAGE NOSE SECTION.
B. Attach a tail stand with approximately 300 pounds ballast to tail skid.
C. Carefully raise jacks until all three wheels are clear of the surface.
Jacking
Figure 1
