THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
4C11
39-20-00
ELECTRICAL & ELECTRONIC EQUIPMENT
The following illustrations depict the location and installation of various electrical/electronic components.
Index
Component Figure 1, Sheet No.
Air Conditioning Power Relay (if installed) 5
Alternator Out Switch 6
Ammeter, Dimmer, Low Voltage Monitor Control Assembly 6
Antenna Coupler 5
Battery Bus 2
Battery Shunt 2
Circuit Breaker Panel 3
Dimmer Control Modules 1
Diode 7
External Power Contactor 2
External Power Assembly 2
Ground Blocks 1, 2, 3, & 4 5
Landing Light Relay 4
Master Solenoid 2
Pitot Heat Sensor 4
Radio Master Relay 5
S-TEC Relay 5
Starter Solenoid 8
Vacuum INOP Switches 7
Voltage Regulator 4
