THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 6
Jun 1/03
4C16
39-20-00
Electrical/Electronic Component Locator
Figure 1 (Sheet 5 of 8)
RADIO MASTER RELAY
ANTENNA COUPLER
(GB 4)
(GB 2)
(GB 3)
(GB 1)
S-TEC RELAY
GROUND BLOCKS
AIR CONDITIONING POWER
RELAY (OPTIONAL)
FWD
UNDER INSTRUMENT PANEL
RIGHT SIDE, LOOKING OUTBOARD
