Piper 6XT - Page 1152

THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 6 Feb 19/04
5J12
91-33-10
COMPASS
P22
A
D
B
C
F
1
2
5K
L5W20N
L5T20
L5S20
L5U20
L5F20
2
L3G20N
1
L3G20
PANEL/SWITCH
LIGHTS
L7A20
7.5A
CB-24
L5V20
ALT
TC
CLOCK
A/S
VSI
MAN
PRESS
VG
TACH
DG
TIT
FUEL
OATOXY
QTY
VACELT
AMMETER
HTR SW
DME
PROVISION FOR
COPILOT INSTRUMENTS
L5FF20
INSTR.
PANEL
POST
LIGHTS
DIMMER
ASSY.
105232 26.0 D / G
ELECTRICAL BUS
OIL TEMP
OIL PRESS
CHT
Panel Lights
Figure 5 (Sheet 1 of 2)
Effectivity
3232001 & up 3255001 & up
