THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 10
Jun 1/03
2C22
21-50-00
CHART 2
TEMPERATURE VS. PRESSURE
Refrigerant HFC134a Refrigerant HFC134a
Evaporator Pressure Evaporator Temperature
Gauge Reading psi °F
-5 -27
0 -15
2-9
4-4
60
84
10 7
12 11
14 14
16 17
18 20
20 22
22 25
24 28
26 30
28 33
30 35
32 37
34 39
36 41
38 43
40 45
42 47
44 49
46 51
48 53
50 54
55 58
60 62
65 66
70 69
