27-00-02
Page 27-03
Revised: February 23, 1979
1J22
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont)
Incorrect aileron travel. Aileron control rods not ad- Adjust control rods.
justed properly.
Aileron bellcrank stops not Adjust bellcrank stops.
adjusted properly.
Correct aileron travel can- Incorrect rigging of aileron Rerig controls.
not be obtained by adjust- cables, control wheel and
ing bellcrank stops. control rod.
Control wheel stops before Incorrect rigging between Rerig controls.
control surfaces reach full control wheel and control
travel. cables.
RUDDER CONTROL SYSTEM
Lost motion between rud- Cable tension too low. Adjust cable tension.
der pedals and rudder.
Linkage loose or worn. Check linkage and tighten
or replace.
Broken pulley. Replace pulley.
Bolts attaching rudder to Tighten sector bolts.
sector are loose.
Excessive resistance to rud- System not lubricated Lubricate system.
der pedal movement. properly.
Rudder pedal torque tube Lubricate torque tube bear-
bearing in need of lubri- ings.
cation.
Cable tension too high. Adjust cable tension.
Pulleys binding or rubbing. Replace binding pulleys and/
or provide clearance be-
tween pulleys and brackets.
Nose gear bungees or Replace springs or
springs broken. bungee(s).
