Piper Arrow IV Turbo User Manual

27-00-02
Page 27-06
December 1, 1978
1K1
CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont)
Trim control wheel moves Cables not in place on Install cables properly.
with excessive resistance. pulleys.
(cont)
Trim tab hinge binding. Lubricate hinge. If necessary,
replace.
Cables crossed or routed Check routing of control
incorrectly. cables.
Trim tab fails to reach full System incorrectly rigged. Check and/or adjust rigging.
travel.
Trim drum incorrectly Check and/or adjust rigging.
wrapped.
Trim indicator fails to indi- Trim indicator unit not ad- Adjust trim indicator.
cate correct trim position. justed properly.
FLAP CONTROL SYSTEM
Flaps fail to extend or Control cable broken or Replace or reconnect con-
retract. disconnected. trol cable.
Flaps not synchronized or Incorrect rigging of system. Adjust flaps.
fail to move evenly when
retracted.
Trouble Cause Remedy
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
STABILATOR TRIM CONTROL SYSTEM
FLOOR TRIM (cont)

Piper Arrow IV Turbo Specifications

General

Manufacturer	Piper Aircraft
Model	Arrow IV Turbo
Horsepower	200 hp
Seating Capacity	4
Landing Gear	Retractable tricycle
Range	773 nautical miles
Service Ceiling	20, 000 ft
Fuel Capacity	72 gallons
Propeller	2-blade constant speed
Max Takeoff Weight	2, 900 lb (1, 315 kg)
Stall Speed (Flaps Down)	55 knots
Rate of Climb	1, 000 ft/min
