CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont)
Resistance to stabilator Pulleys binding or rubbing. Replace binding pulleys and/
control movement. (cont) or provide clearance between
pulleys and brackets.
Cables not in place on Install cables correctly.
pulleys.
Cables crossed or routed Check routing of control
incorrectly. cables.
Bent stabilator hinge. Repair or replace stabilator
hinge.
Incorrect stabilator travel. Stabilator stops incorrectly Adjust stop screws.
adjusted.
Correct stabilator travel Stabilator cables incor- Rerig stabilator cables.
cannot be obtained by ad- rectly rigged or incorrect
justing stops. stop in control column. Replace stop.
Lost motion between trim Cable tension too low. Adjust cable tension.
control wheel and trim tab.
Cables not in place on Install cables properly.
pulleys.
Broken pulley. Replace pulley.
Linkage loose or worn. Check linkage and tighten or
replace.
Trim control wheel moves System not lubricated Lubricate system.
with excessive resistance. properly.
Cable tension too high. Adjust cable tension.
Pulleys binding or rubbing. Replace binding pulleys.
Provide clearance between
pulleys and brackets.
