8
Parts are located throughout the shipping carton, including inside the electric smoker. Inspect the
unit, parts, and hardware blister pack after removing from the protective shipping carton. Before
assembly of product, review all parts and reference the parts list. If any part is missing or
damaged, do not attempt to assemble. Shipping damage is not covered under warranty. Contact your
dealer or Pit Boss Customer Service for parts.
IMPORTANT: To ease installation, it is recommended two people is helpful when assembling this unit.
Tools required for assembly: screwdriver and wrench. Tools is not included.
IMPORTANT: It is advised to read each step entirely before starting assembly on instructions. Do not
tighten screws completely until all screws for that step have been installed, or unless otherwise
mentioned.
ASSEMBLY PREPARATION
ASSEMBLY INSTRUCTIONS
1.
MOUNTING THE CASTERS TO LEGS
Parts Required:
2 x 2.5” Caster with Lock (#21)
2 x 2.5” Caster (#22)
1 x Right Rear Leg (#15)
1 x Left Rear Leg (#17)
1 x Right Front Leg (#16)
1 x Left Front Leg (#18)
16 x 1/4-20*1/2”Screw (#B)
Installation:
• Place a piece of cardboard on the floor to
prevent scratching the unit.
• Remove the Door Assembly (#8) and set
aside.
Mount 2 x 2.5” Caster with Lock (#21) to
Right Rear Leg (#15) and Left Rear Leg
(#17) using 8 x1/4-20*1/2”Screws (#B)as
Fig.1.1 shown.
• Mount 2 x 2.5” Caster (#22) to Right Front
Leg (#16) and Left Front Leg (#18) using
8x1/4-20*1/2”Screws (#B)as Fig.1.2 shown.
Fig.1.1
Fig.1.2
#22
#21
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
---------
--
----
#15
--
-
-
-
-
-
-
-
-
-
-
-
#17
-
-
--
-
-
-
--
#18
--
-
-
-
--
-
-
-
-
--
-
#16
-
-
-
-
-
-
-
-
-
-
-
-
-
To Next Page
