J693 23
Printer Options (continued)
GPIO PORT
The physical presence of the optional GPIO
port must be detected to show the selections in
the menu system.
GPIO
Instructs the printer to update the output
signals and to wait for the Start of Print Signal
to print a label.
ENABLED
Yes
DISABLED
No
END OF PRINT
Defines the operation of the printer’s End of
Print signal as sent to the applicator. This
signal indicates that the printer has completed
the print cycle.
LOW STATUS
A steady Low (0 VDC) during the print cycle.
HIGH STATUS
A steady High (5 VDC) during the print cycle.
LOW PULSE
A Low Pulse (0 VDC for 30 ms) at the end of
print.
HIGH PULSE
A High Pulse (5 VDC for 30 ms) at the end of
print.
DISABLED
No indication.
