Pitney Bowes J693 - Appendix C Module Assignments; Print Resolutions and Maximum Widths

J693 87
&
Module Assignments
Memory Module
Designator Module Size Volatile* Location / Use
A Future Option N/A N/A
B Future Option N/A N/A
D
1024 KB
(default size)
Yes Main PCB SDRAM – user
addressable for graphics, fonts, and
label formats
F 4 MB No Optional Flash Card – user
addressable for graphics, fonts, and
label formats
Y 64 KB No Main PCB Flash – reserved for
EFIGS
Z 4 MB No Optional Flash Card – reserved for
ILPC
*When power is removed from the printer, stored data will be lost.
Print Resolutions and Maximum Widths
Resolutions and Widths
Maximum Print
Width
Model Printhead Resolution
Inches Millimeters
Factory Default
Setting
J693 203 dots/inch
(8 dots/mm)
4.09 103.9 4.10
