Step 1 Step 3Step 2
Gyroscope Sensor Mount Assembly
Digilent Gyro Sensor 41144
Digilent Sensor Mounting Clip 41148
Thumbscrew 40323
4-Hole Beam 40201
Wing Nut 40221
28 Subassembly Construction Instructions
