Step 6
Finished assembly should look like this.
Parts Needed
2x
Thumbscrew 40323
1x
Digilent Sensor
Mounting Clip 41148
1x
myRIO Controller
2x
Wing Nut 40221
Rotate build to match this view.
1x
10-Cell AA NiMH
Battery Pack 41135
1x
Digilent Sensor
IR Rangefinder with
Mounting Plate
1x
Gripper Kit 40234
Rover Vehicle Assembly 73
