The system is compatible with the following Android versions:
• 4.4
• 5.0 - 5.1
• 6.0
• 7.0 - 7.1
• 8.0
• 9.0 and subsequent
DISPENSER
Composed of an electronic controller to manage fuel dispensing, equipped with:
• Numeric display
• Reader for iButton
• BLE 4.0 connection (or following)
• Status sensors for: level alarms, flow meters, positioning of the
dispensing nozzle
• Pump on/off control
CLOUD Where there is the database to store the configurations of the site and the
dispenser, the drivers, the license plates of the vehicles and all the dispensings
WebApp Web interface used by the site manager. It has various functions: it monitors
the dispensings (from whom they were made, when, in which fuel dispenser),
creates/eliminates users from the site, adds/removes fuel dispensers from the
site. The only external device the WebApp connects to is a USB reader for
iButton
APP It makes several operations:
• It manages two types of users: driver and manager
• It sends commands to the fuel dispenser and receive answers, the
commands are used to perform: dispensing, calibration, updating
the firmware of the fuel dispenser, downloading updates of the fuel
dispenser configuration, managing the drivers or loading in the cloud
the dispensings in the fuel dispenser
iBuon
WebApp
APP
iBuon
Cloud
Database
CUBE B.SMART
