Installation, use and maintenance
M0546
18 /6 0
24 V dc
auxiliary power
supply output
24 V dc auxiliary
output to supply
external electronic
devices
Imax = 25 mA The device to be supplied must not
absorb more than 25 mA with 24 V
dc power supply. Typically it could be
a level sensor
Fuses
F1 (V ac power input) 800 mA T (delayed)
F2 (motor output) 20 A T (delayed)
F3 (AC/DC output) 800 mA T (delayed)
IP protection
degree
IP 55
Operating
temperature
From -10°C to +40°C
Storage
temperature
From -20°C to +60°C
Humidity
< 90%
Wiring
distances
Max. pulser
distance
15 m
Max. level sensor
distance
100 m
Displaying and
Metering limits
The floating point sequence: 0.00 -> 99.99 -> 999.9 -> 9999
The maximum quantity that can be dispensed is 9999 units regardless of the unit of
measurement set litres/gallons/pints
0.00 9,999 99.99 999.9 9999
PRESET: Presettable
maximum quantity
9999 litres/gallons/
pints
Memories
The electronic controller can store:
- Up to 500 drivers
- Up to 500 dispensings
